| Ref | Part Number | Description |
|---|
| 1 |
32120-8 |
RING-SNAP Price: $1.76 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 2 |
583512701 |
SUBASM.AXLE.CAST.NZTR. This part replaces 532436870. Price: $169.99 |
| 2 |
72-3750 |
BEARING-ROLLER Price: $180.02 |
| 3 |
323-56 |
SCREW-HH Price: $2.18 |
| 4 |
67-9080 |
HOUSING-MOTOR Price: $1,756.34 |
| 5 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 6 |
25-2650 |
PLUG-VALVE, CHECK Price: $89.01 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
237-86 |
O-RING Price: $5.47 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
25-2640 |
SPRING-VALVE Price: $4.22 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
25-2490 |
BALL Price: $14.47 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
67-9100 |
GASKET Price: $15.83 |
| 11 |
99-5689 |
CHECK VALVE KIT This part replaces 25-3180. Price: $83.29 |
| 12 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 13 |
237-22 |
O-RING Price: $2.43 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
25-2630 |
RING-BACK UP Price: $3.55 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 15 |
88-8220 |
VALVE-BY PASS This part replaces 25-2620. Price: $189.03 |
| 16 |
25-2610 |
SPRING-VALVE Price: $29.42 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532444212. Price: $34.99 |
| 17 |
25-2410 |
VALVE ASM Price: $514.54 |
| 18 |
76-1900 |
O-RING Price: $3.64 |
| 19 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
119-2895 |
SPLINED SHAFT KIT This part replaces 67-8020. Price: $1,116.09 |
| 21 |
3257-32 |
KEY-WOODRUFF Price: $2.52 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532437747. Price: $7.99 |
| 22 |
117-2700 |
HOUSING KIT This part replaces 54-7890. Price: $2,321.28 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 23 |
252-82 |
BEARING-NEEDLE Price: $51.31 |
| 24 |
25-3210 |
SEAL-LIP Price: $23.14 |
| 25 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 26 |
25-2580 |
SHAFT-TRUNNION Price: $215.33 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 28 |
25-2460 |
PLUG-HH Price: $37.38 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 30 |
25-2570 |
SPRING-VALVE Price: $12.67 |
| 31 |
83-7260 |
CONE-RELIEF, CHARGE This part replaces 25-2560. Price: $50.57 |
| 32 |
353-551 |
PLUG-HH Price: $18.48 |
| 33 |
237-80 |
O-RING Price: $6.10 |
| 34 |
25-2550 |
DISCONTINUED-SEE PB#945 Price: Call Us |
| 35 |
583551401 |
GEAR.SECTOR.TEX.NZTR This part replaces 532440770. Price: $39.99 |
| 35 |
67-8050 |
BEARING-NEEDLE Price: $54.10 |
| 36 |
93-4133 |
SEAL-LIP Price: $37.43 |
| 37 |
322-4 |
SCREW-HH Price: $0.35 |
| 38 |
25-2680 |
GEROTOR ASM Price: $651.02 |
| 39 |
25-2530 |
PIN-STRAIGHT, HEADLESS Price: $21.24 |
| 40 |
25-3190 |
DISCONTINUED-SEE PB#945 Price: Call Us |
| 41 |
237-95 |
O-RING Price: $11.97 |
| 42 |
67-9090 |
PLUG Price: $41.68 |
| 43 |
25-2500 |
SHAFT-TRUNNION Price: $191.66 |
| 44 |
25-2480 |
SPRING-VALVE Price: $4.93 |
| 45 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 46 |
251-8 |
BEARING-BALL Price: $30.06 |
| 47 |
32151-75 |
RING-RETAINING This part replaces 32120-11. Price: $2.51 |
| 48 |
25-2450 |
PLATE-SWASH, VARIABLE Price: $896.81 |
| 49 |
32121-91 |
PIN-SPRING Price: $0.81 |
| 50 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 51 |
25-2440 |
PLATE-VALVE, PUMP Price: $491.90 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 52 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 53 |
110-6341 |
BEARING-ROLLER This part replaces 46-8400. Price: $41.33 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
93-4132 |
O-RING Price: $6.84 |
| 55 |
92-8918 |
SECTION-CENTER Price: $1,338.76 |
| 57 |
25-2390 |
PLATE-VALVE, MOTOR Price: $832.97 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
46-8410 |
SHAFT-MOTOR Price: $968.23 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
25-2400 |
GASKET Price: $19.26 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 60 |
74-9510 |
WASHER-PLAIN Price: $0.65 |
| 61 |
597069802 |
LINKAGE SUBASM LINK DRAG LH N This part replaces 532436884. Price: $29.99 |
| 61 |
75-0170 |
PLUG-THREAD, STRAIGHT This part replaces 92-8776. Price: $18.20 |
| 62 |
597069902 |
Links This part replaces 532436885. Price: $29.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 80 |
532001370 |
THRUST WASHER Price: $4.99 |
| 81 |
597069702 |
Links This part replaces 532436887. Price: $9.99 |
| 82 |
532436877 |
Price: Call Us |
| 85 |
529846901 |
SERVICE KIT SUBASM.PIVOT.RH.NZ This part replaces 532441873. Price: $17.99 |
| 86 |
583561001 |
SUBASM.PIVOT.LH.NZTR This part replaces 532441872. Price: $27.99 |
