| Ref | Part Number | Description |
|---|
| 1 |
43-6840 |
HOUSING-LOWER This part replaces 24-8820. Price: $1,467.48 |
| 1 |
530016386 |
Screw Price: $5.99 |
| 2 |
530056450 |
Assy-Shroud Price: $11.99 |
| 2 |
72-9420 |
VENT This part replaces 21-8230. Price: $6.85 |
| 3 |
3219-2 |
NUT-HEX Price: $0.37 |
| 3 |
530071486 |
O-Ring-Shrd (kit) Price: $5.99 |
| 4 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 4 |
545145801 |
CRANKSHAFT ASSY This part replaces 530028802. Price: $17.99 |
| 5 |
21-8280 |
DISCONTINUED Price: Call Us |
| 6 |
21-8270 |
PIN-DOWEL Price: $6.65 |
| 6 |
530015941 |
Ring-Retainer-C'shaft Price: $1.99 |
| 7 |
21-7770 |
SCREW-GEAR, DRIVE Price: $1.97 |
| 7 |
545221701 |
FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 8 |
21-7670 |
CASE-DIFFERENTIAL Price: $687.90 |
| 8 |
530015828 |
Washer-Flat Price: $1.99 |
| 9 |
21-7700 |
SHAFT-MATE, PINION Price: $54.05 |
| 9 |
530055729 |
Spacer-Flywheel Price: $7.99 |
| 10 |
21-7720 |
WASHER-THRUST Price: $3.39 |
| 10 |
530015496 |
Screw Price: $1.99 |
| 11 |
248790 |
Differential Bevel Side Gear Price: Call Us |
| 11 |
530055681 |
Plate-Baffle Price: $2.99 |
| 12 |
110-4143 |
KIT-REPLACEMENT, REVACYCLE GEARS This part replaces 21-7690. Price: $702.98 |
| 12 |
530015882 |
Screw Price: $1.99 |
| 13 |
21-7730 |
WASHER-THRUST, PINION Price: $2.65 |
| 14 |
530055762 |
Assy-Fan Housing Price: $14.99 |
| 15 |
21-8080 |
DISCONTINUED Price: Call Us |
| 15 |
530027569 |
Handle-Starter Price: $1.99 |
| 16 |
530069232 |
Kit-Rope Price: $3.99 |
| 16 |
92-1773 |
SCREW-HHF This part replaces 324-23. Price: $3.05 |
| 17 |
12-5450 |
SCREW Price: $7.99 |
| 17 |
530019182 |
Grommet-Ignition Module Price: $1.99 |
| 18 |
21-7830 |
COVER-GEAR Price: $26.87 |
| 18 |
530016386 |
Screw-(f/hsg to shrd) Price: $5.99 |
| 19 |
545008010 |
STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 19 |
86-7230 |
GEAR-INPUT, TRANSMISSION This part replaces 21-8150. Price: $610.12 |
| 20 |
21-7820 |
DISCONTINUED Price: Call Us |
| 20 |
530016357 |
Screw Price: $1.99 |
| 21 |
21-8030 |
DISCONTINUED Price: Call Us |
| 21 |
530039163 |
Ignition Module GHT 180/220 Price: $34.99 |
| 21 |
530054137 |
Ignition Module GHT 220 CAN. Price: $32.99 |
| 22 |
21-8040 |
DISCONTINUED Price: Call Us |
| 22 |
530071627 |
Assy-Crankcase Price: $17.99 |
| 23 |
21-8050 |
BRG SHIM .010 Price: $6.29 |
| 23 |
530055728 |
Bearing-Outer Price: $6.99 |
| 24 |
21-8060 |
DISCONTINUED Price: Call Us |
| 24 |
530071615 |
Kit-Crankcase Seal Price: $4.99 |
| 25 |
28-0640 |
DISCONTINUED Price: Call Us |
| 25 |
530032125 |
Bearing-Inner Price: $11.99 |
| 26 |
530015934 |
Screw Price: $1.99 |
| 26 |
99-5691 |
SCREW W/WASHER This part replaces 28-0660. Price: $7.18 |
| 27 |
254-90 |
BEARING-CUP This part replaces 21-8390. Price: $11.29 |
| 27 |
530071486 |
Gasket-Cylinder (kit) Price: $5.99 |
| 28 |
21-8010 |
BRG CONE Price: $30.15 |
| 28 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 29 |
32151-83 |
RING-SNAP This part replaces 32120-32. Price: $0.34 |
| 30 |
21-7850 |
PLUG-CUP Price: $23.35 |
| 30 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 31 |
21-7870 |
DISCONTINUED Price: Call Us |
| 31 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 32 |
21-8020 |
SPACER-BEARING Price: $28.84 |
| 32 |
530015953 |
Screw Price: $1.99 |
| 33 |
530071486 |
Gasket-Carb. Adapt.(kit) Price: $5.99 |
| 34 |
21-8070 |
DISCONTINUED Price: Call Us |
| 34 |
530057634 |
Adapter-Carburetor Price: $8.99 |
| 35 |
2544-6 |
Cup-Tapered Bearing Price: Call Us |
| 35 |
530016014 |
Screw Price: $1.99 |
| 36 |
2544-5 |
Cone-Tapered Bearing Price: Call Us |
| 36 |
530071633 |
Kit-Carburetor Ass'y. (C1U-W13A) Price: $32.99 |
| 37 |
32121-15 |
PIN-ROLL This part replaces 21-7710. Price: $1.60 |
| 37 |
530055680 |
Air Box Price: $2.99 |
| 38 |
21-8090 |
SHIM-BEARING, DIFFERENTIAL (.003) Price: $1.09 |
| 38 |
530016394 |
Screw Price: $3.33 |
| 39 |
21-8100 |
SHIM-BEARING, DIFFERENTIAL (.005) Price: $3.46 |
| 39 |
530047932 |
Air Filter Foam Price: $1.99 |
| 40 |
21-8110 |
SHIM-BEARING, DIFFERENTIAL (.010) Price: $3.73 |
| 40 |
530055679 |
Air Filter Cover Price: $1.99 |
| 41 |
21-8120 |
SHIM-BEARING, DIFFERENTIAL (.030) Price: $5.43 |
| 41 |
530015957 |
Screw Price: $1.99 |
| 42 |
530015123 |
Washer This part replaces 530015158. Price: $1.99 |
| 43 |
530071486 |
Gasket-Carburetor (kit) Price: $5.99 |
| 44 |
530055547 |
Assy-Throttle Cable Price: $5.99 |
| 45 |
952030249 |
Spark Plug(RCJ-6Y) Price: $3.99 |
| 46 |
530012416 |
Cylinder This part replaces 530071359. Price: $17.99 |
| 47 |
530042088 |
Spring-Muffler Price: $1.99 |
| 49 |
530095992 |
Assy-Pick-up Price: $5.99 |
| 50 |
530069247 |
Kit-Fuel Line (small) Price: $3.99 |
| 51 |
530069216 |
Kit-Fuel Line (large) Price: $3.99 |
| 52 |
530023877 |
Fitting-Fuel Line Price: $1.99 |
| 53 |
530016103 |
Clip-Retainer Price: $1.99 |
| 55 |
530071731 |
Kit-Module Spacer & Screws Price: $4.99 |
