Work Light (Part 2)
Parts (36)
| Ref | Part Number | Description |
|---|---|---|
| 1 | None | Reflector, Component |
| 1 | 539112700 | SEAT.HIGHBACK.GREY.ZTR This part replaces 539130825. Price: $279.99 |
| 1 | 539130826 | SEAT.XH150.LOWBACK.GREY.ZTR Price: $169.99 |
| 2 | None | Housing, Component |
| 2 | 539112694 | SEAT MOUNT, BLACK Price: $44.99 |
| 3 | None | Lead, Component |
| 3 | 597783101 | GSPW Knobs This part replaces 539104411. Price: $3.99 |
| 4 | 596240701 | Bolts This part replaces 539110303. Price: $3.99 |
| 5 | 596433701 | GSPW Washers This part replaces 539990517. Price: $2.99 |
| 6 | 532124238 | CAP SPRING This part replaces 539110301. Price: $4.99 |
| 6 | MA-09808122304 | BULB Not Available Price: |
| 7 | 587613301 | SPRING.COMPRESSION.SEAT.BLACK This part replaces 539110300. Price: $5.99 |
| 7 | MA-12087711100 | LENS Not Available Price: |
| 8 | 596583702 | Nuts This part replaces 539990717. Price: $2.99 |
| 8 | MA-12087711300 | GASKET Not Available Price: |
| 9 | None | Rim |
| 9 | 539976941 | HCS 3/8C X 1 1/4 GR5 Price: $3.99 |
| 10 | 538110126 | REAR SEAT SUPPORT Price: Call Us |
| 10 | MA-F3000106000 | NUT Not Available Price: |
| 11 | 539132140 | SWITCH, SEAT N/C Price: $12.99 |
| 11 | MA-12087711700 | STAY Not Available Price: |
| 12 | MA-F1040106016 | BOLT Not Available Price: |
| 13 | MA-04322104020 | SCREW, TAPPING Not Available Price: |
| 16 | MA-F1540108025 | BOLT,W/SPRING WASH Not Available Price: |
| 17 | MA-03500140818 | WASHER Not Available Price: |
| 18 | MA-A3010108002 | NUT Not Available Price: |
| 20 | MA-12187745AG0 | BRACKET Not Available Price: |
| 27 | 3220-6 | NUT-JAM Price: $1.25 |
| 28 | 66-9770 | SEAL Price: $20.05 |
| 29 | 66-9780 | BUSHING Price: $11.69 |
| 36 | 93-3609 | BOLT-SPECIAL Price: $23.98 |
| 37 | 66-9860 | UPPER COVER AND JACKET ASM Price: $222.25 |
| 38 | 66-9870 | PLATE-RETAINING Price: $9.64 |
| 39 | 66-9880 | WASHER-PLATE, RETAINING Price: $0.98 |
| 40 | 66-9890 | RING-RETAINING Price: $4.93 |
| 41 | 66-9900 | SHAFT-INPUT Price: $170.42 |
