| Ref | Part Number | Description |
|---|
| 1 |
531222001 |
COMBINATION WRENCH COMBI TOOL This part replaces 503558501. Price: $5.99 |
| 1 |
603-04012 |
LOWER ROPS ASSEMBLY Not Available Price: |
| 2 |
531222001 |
COMBINATION WRENCH COMBI TOOL This part replaces 501691701. Price: $5.99 |
| 2 |
703-05032-0637 |
REAR SEAT BRACKET (POWDER BLACK) Not Available This part replaces 703-05032. Price: |
| 3 |
503558602 |
L-SPANNER Price: $2.99 |
| 3 |
703-05770 |
HAZARD LAMP PLATE Not Available Price: |
| 4 |
503558601 |
L-SPANNER Price: $2.99 |
| 4 |
710-0514 |
Screw, Hex Cap, 3/8-16 x 1.0 GR5 Price: $3.78 |
| 5 |
503551601 |
OIL CAP This part replaces 503621201. Price: $6.99 |
| 5 |
710-1260A |
Screw, Hex Wash. Hd. Tapp 5/16-18 x .75 Price: $3.34 |
| 6 |
501911402 |
GREASES This part replaces 501911401. Price: $7.99 |
| 6 |
710-3032 |
Screw, Hex Cap, 1/2-13 x 1.25 GR5 Price: $5.66 |
| 7 |
710-3038 |
Screw, Hex Cap, 5/16-18 x .875 GR5 Price: $4.17 |
| 8 |
503217016 |
SCREW Price: $2.99 |
| 8 |
712-04065 |
Nut, Hx. Insert Flange Lck, 3/8-16 GRF Price: $3.68 |
| 9 |
912-3066 |
Hex Nut, 1/2-20 This part replaces 712-3066. Price: $6.01 |
| 10 |
925-04266 |
HAZARD LAMP ASSEMBLY Not Available This part replaces 725-04266. Price: |
| 11 |
726-0211 |
Nut, Speed, 5/16-18 Price: $3.90 |
| 12 |
731-0757 |
CONVOLUTED CONDUIT Not Available Price: |
| 13 |
736-0148 |
Washer, Ext. Tooth Lock, 3/8 Price: $3.19 |
| 14 |
736-0185 |
Washer, Flat, .375 x .738 x .063 Price: $3.43 |
| 15 |
736-0272 |
FLAT WASHER .510 x .995 This part replaces 7360272. Price: $4.37 |
| 16 |
736-0921 |
Washer, Lock, 1/2 Price: $3.90 |
| 17 |
736-3089 |
FLAT WASHER .345X1.0X.100 Not Available Price: |
| 18 |
711-04393 |
PIN .50 x 2.5 Not Available Price: |
| 19 |
759-04038 |
FOLDING ROPS ASSEMBLY Not Available Price: |
| 20 |
None |
Order 759-04038 |
| 21 |
None |
Order 759-04038 |
| 22 |
736-0600 |
FLAT WASHER .558X.866X.078 Not Available Price: |
| 23 |
914-3003 |
INTERNAL COTTER PIN Not Available This part replaces 714-3003. Price: |
| 24 |
731-05131A |
SEAT ADJUST KNOB 3/8-16 x 1.50 This part replaces 731-05131. Price: $12.34 |
| 25 |
712-3083 |
Nut, Hex Insert Lock, 1/2-13 Price: $4.05 |
