| Ref | Part Number | Description |
|---|
| 1 |
579841401 |
KITS.CHASSIS.STAMPED.SERVICE This part replaces 532174619. Price: $379.99 |
| 1 |
94-1257 |
DISCONTINUED Price: Call Us |
| 2 |
107-4803 |
CAP-SEALING This part replaces 42-7080. Price: $14.47 |
| 2 |
532176554 |
DRAWBAR, 12GA Price: $37.99 |
| 2 |
KB-16861-72330 |
FAN SHROUD Not Available Price: |
| 3 |
75-4900 |
BRG SET, CRANKSHAFT STD Price: $187.56 |
| 3 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 3 |
KB-16861-72020 |
CAP-RADIATOR Not Available Price: |
| 4 |
67-2200 |
SEAL Price: $11.20 |
| 4 |
KB-16851-73110 |
COCK-DRAIN Not Available Price: |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 5 |
67-2250 |
DISCONTINUED Price: Call Us |
| 5 |
KB-16851-72712 |
HOSE-OVER Not Available Price: |
| 6 |
KB-16851-72470 |
HOSE CLAMP Not Available Price: |
| 7 |
67-3010 |
CAM SHAFT Price: $1,102.40 |
| 7 |
KB-16851-96690 |
GASKET Not Available Price: |
| 8 |
56-0480 |
WOODRUFF KEY Price: $3.88 |
| 8 |
KB-16851-72400 |
OVERFLOW TANK Not Available Price: |
| 9 |
532168336 |
DASH This part replaces 532171853. Price: $33.08 |
| 9 |
67-3030 |
DISCONTINUED Price: Call Us |
| 9 |
KB-16851-72420 |
CAP Not Available Price: |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 10 |
67-3000 |
DISCONTINUED Price: Call Us |
| 10 |
KB-16851-72440 |
HOSE-DRAIN Not Available Price: |
| 11 |
42-9490 |
SCREW - CAP Price: $0.30 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX This part replaces 532155927. Price: $9.99 |
| 11 |
KB-01205-50614 |
Bolt Price: Call Us |
| 12 |
532145660 |
CLIP Price: $2.99 |
| 12 |
67-3020 |
GEAR Price: $533.60 |
| 12 |
KB-16861-72850 |
HOSE-LOWER RADIATO Not Available Price: |
| 13 |
532173025 |
PANEL DASH RH Price: $9.92 |
| 13 |
67-3090 |
GEAR ASSEMBLY Price: $393.33 |
| 13 |
KB-16871-72940 |
HOSE-RADIATOR Not Available Price: |
| 14 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 14 |
67-3040 |
PLATE Price: $13.46 |
| 14 |
KB-09318-89030 |
HOSE CLAMP Not Available Price: |
| 15 |
56-1060 |
DISCONTINUED Price: Call Us |
| 15 |
KB-09318-89036 |
HOSE CLAMP Not Available Price: |
| 16 |
KB-02054-50050 |
FLANGE NUT Not Available Price: |
| 17 |
532159639 |
HOOD.STEEL.LT.ORANGE This part replaces 532162237. Price: $64.99 |
| 17 |
67-3070 |
GEAR Price: $237.67 |
| 17 |
703-2021A |
MOUNT-RADIATOR Not Available Price: |
| 18 |
532126938 |
BUMPER HOOD T Price: $3.99 |
| 18 |
603-0042 |
BRACKET-RADIATOR SUPPORT Not Available Price: |
| 19 |
603-0001A |
BAFFLE Not Available Price: |
| 20 |
42-7840 |
SUNK KEY Price: $9.67 |
| 20 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 21 |
67-3060 |
SHAFT Price: $394.25 |
| 21 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 22 |
67-3050 |
BEARING Price: $29.09 |
| 22 |
710-3136 |
SCREW M10-1-25 Not Available Price: |
| 23 |
67-3080 |
SNAP RING Price: $1.67 |
| 23 |
712-3006 |
HEX NUT Price: $4.05 |
| 24 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 24 |
712-3010 |
HEX NUT 5/16-18 This part replaces 7123010. Price: $3.89 |
| 25 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 25 |
723-3060 |
HEAT BAFFLE SEAL Not Available Price: |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 26 |
703-2171 |
Baffle, Radiator LH Price: Call Us |
| 28 |
532179100 |
GRILL ASSEMBLY Price: $169.99 |
| 28 |
703-2170 |
Baffle, Radiator RH Price: Call Us |
| 29 |
532140273 |
LENS This part replaces 532168154. Price: $16.99 |
| 30 |
532175274 |
FENDER This part replaces 532176953. Price: $107.99 |
| 30 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 31 |
532136619 |
BRACKET FENDER Price: $4.99 |
| 31 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 32 |
736-0407 |
Washer, Bell, .45 X 1.0 X .062 Price: $3.64 |
| 33 |
532182507 |
FOOTREST.LH.BLACK This part replaces 532181057. Price: $37.99 |
| 33 |
735-3043 |
FLAP-RAD BOTTOM Not Available Price: |
| 34 |
532182508 |
FOOTREST.RH.BLACK This part replaces 532181058. Price: $22.99 |
| 34 |
KB-15409-94610 |
LABEL-RAD. Not Available Price: |
| 35 |
596136001 |
Bolts This part replaces 872110606. Price: $3.99 |
| 35 |
KB-66101-47330 |
LABEL Not Available Price: |
| 36 |
710-0294 |
HEX CAP SCREW 1/4-20 x .375 GR5 Not Available Price: |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR Price: $9.99 |
| 51 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 52 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 53 |
532144697 |
BRACKET.GRILLE.LH Price: $4.99 |
| 54 |
532161464 |
SCREW.HEX.WS.HD.8-18 X 7/8 Price: $3.99 |
| 55 |
532144696 |
BRACKET Price: $4.99 |
| 57 |
596230901 |
Screws This part replaces 874780412. Price: $2.99 |
| 58 |
532150127 |
AIR DUCT P/L/LT Price: $13.99 |
| 64 |
532154798 |
DASH LOWER Price: $17.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT Price: $7.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 206 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 207 |
817670508 |
SCREW, 5/16-18 X 1/2 Price: $7.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 212 |
532174503 |
INSERT, LENS This part replaces 532156229. Price: $22.99 |
