| Ref | Part Number | Description |
|---|
| 1 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 1 |
539105778 |
DECK W/DECALS 42" Price: $989.48 |
| 2 |
56-7974 |
CLAMP-TUBE Price: $2.17 |
| 2 |
596671501 |
Washers This part replaces 539101949. Price: $2.99 |
| 3 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 3 |
539976828 |
ROLLER Price: $25.07 |
| 4 |
32153-6 |
NUT-LOCK Price: $3.46 |
| 4 |
539103437 |
AXLE Price: $9.99 |
| 5 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 5 |
539103274 |
BLADE OEM, 14-7/8 Price: $17.99 |
| 6 |
69-6170 |
TUBE-HYD Price: $211.81 |
| 6 |
966956001 |
KIT, HSG ASM - 42/48 This part replaces 539108772. Price: $169.99 |
| 7 |
539108754 |
SHAFT SEAL Price: $6.99 |
| 7 |
69-9450-03 |
BRACKET-HOSE, WING (LH) This part replaces 69-9450. Price: $26.57 |
| 8 |
240-3 |
GROMMET-RUBBER Price: $17.44 |
| 8 |
539108758 |
SPACER Price: $1.55 |
| 9 |
125-1984 |
SPACER This part replaces 69-9000. Price: $0.68 |
| 9 |
539108759 |
SPLINED SHAFT - 42/48" Price: $99.99 |
| 10 |
539108449 |
BOTTOM DUST CAP Price: $3.99 |
| 10 |
69-9010 |
WASHER Price: $1.83 |
| 11 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 11 |
539108450 |
TOP DUST CAP Price: $4.99 |
| 12 |
323-6 |
SCREW-HH Price: $0.66 |
| 12 |
539977326 |
PLUG-VENTED Price: $8.99 |
| 13 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 13 |
69-9761 |
PLATE-COVER Price: $6.26 |
| 14 |
539103299 |
HCS 5/8F X 1 1/4 Price: $5.99 |
| 15 |
340-70 |
NUT-LOCK Price: $2.10 |
| 15 |
539990333 |
LOCKWASHER 5/8 Price: $2.99 |
| 16 |
539105361 |
DISCHARGE CHUTE 42" Price: $109.99 |
| 16 |
69-8940 |
WASHER Price: $1.76 |
| 17 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 539976934. Price: $3.99 |
| 17 |
69-8970 |
SPACER Price: $9.57 |
| 18 |
240-4 |
GROMMET-RUBBER Price: $9.91 |
| 18 |
539102619 |
PIVOT PIN Price: $32.99 |
| 19 |
237-22 |
O-RING Price: $2.43 |
| 19 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 20 |
237-65 |
O-RING Price: $2.50 |
| 20 |
539105435 |
CENTER BAFFLE Price: $59.99 |
| 21 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 21 |
69-5980 |
HYDRAULIC TUBE Price: $97.40 |
| 22 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 22 |
69-6180 |
TUBE-HYD Price: $136.16 |
| 23 |
32152-4 |
NUT-LOCK, CONE Price: $1.29 |
| 23 |
539105439 |
MAIN BAFFLE Price: $179.99 |
| 24 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 24 |
539108350 |
STRUT, RIGHT This part replaces 539104609. Price: $549.99 |
| 25 |
32108-103 |
SCREW-FH Price: $0.68 |
| 25 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 26 |
539104199 |
HCS 5/8C X 2 GR.5 Price: $2.99 |
| 26 |
99-5917 |
SHAFT-PIVOT, LIFT ARM This part replaces 71-2580. Price: $381.77 |
| 27 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 27 |
539104197 |
STRUT MOUNT WELDMENT Price: $51.99 |
| 28 |
328-26 |
SCREW-HH Price: $38.75 |
| 28 |
594944601 |
Bolts This part replaces 539101175. Price: $2.99 |
| 29 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 29 |
594722002 |
LIFT This part replaces 539102641. Price: $4.99 |
| 30 |
539990839 |
NUT 7/16C CENTERLOCK Price: $2.99 |
| 30 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 31 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 31 |
596577901 |
Nuts This part replaces 539102582. Price: $2.99 |
| 32 |
539112120 |
HCS 7/16-20 GD 8 SPEC This part replaces 539108766. Price: $24.99 |
| 32 |
72-4310 |
SWITCH-BALL Price: $84.47 |
| 33 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 33 |
71-0160 |
DISCONTINUED Price: Call Us |
| 34 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 34 |
69-9300 |
PAD-BUMPER Price: $8.68 |
| 35 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 35 |
539103240 |
BELT, DECK 42" Price: $109.99 |
| 36 |
328-8 |
SCREW-HH Price: $5.54 |
| 36 |
539112141 |
PULLEY 42-48 This part replaces 539107276. Price: $37.99 |
| 37 |
328-10 |
SCREW-HH Price: $14.93 |
| 37 |
539103258 |
IDLER PULLEY (TALL) Price: $44.99 |
| 38 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 38 |
98-7346 |
SPACER This part replaces 69-9190. Price: $30.67 |
| 39 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 39 |
69-5490 |
HOSE ASM Price: $89.51 |
| 40 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 40 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 41 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 41 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 42 |
237-42 |
O-RING Price: $2.78 |
| 42 |
539103256 |
SPRING Price: $9.99 |
| 43 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 43 |
74-2170 |
HYD CYLINDER ASM Price: $1,341.49 |
| 44 |
323-15 |
SCREW-HH Price: $1.53 |
| 44 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 45 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 45 |
74-2680-03 |
BRACKET-BULKHEAD This part replaces 74-2680. Price: $34.49 |
| 46 |
539103230 |
IDLER ARM Price: $159.99 |
| 46 |
69-6030 |
TUBE-HYD Price: $144.98 |
| 47 |
539103427 |
PIVOT BUSHING Price: $7.99 |
| 47 |
69-6060 |
TUBE-HYD Price: $131.82 |
| 48 |
539108898 |
LT 42 SHIELD Price: $39.99 |
| 48 |
69-6070 |
TUBE-HYD Price: $115.22 |
| 49 |
596437501 |
Washers This part replaces 539102243. Price: $8.99 |
| 49 |
69-6000 |
TUBE-HYD Price: $148.33 |
| 50 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 50 |
69-6040 |
TUBE-HYD Price: $150.53 |
| 51 |
539102612 |
SCREW 3/8C X 2 3/4 HEX CAP Price: $4.99 |
| 51 |
69-6050 |
TUBE-HYD Price: $125.05 |
| 52 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 52 |
69-6080 |
TUBE-HYD Price: $115.22 |
| 53 |
539102892 |
DECAL, NO STEP Price: $0.64 |
| 53 |
69-5990 |
TUBE ASM Price: $181.00 |
| 54 |
539913010 |
DECAL, CPSC Price: $3.99 |
| 54 |
69-4400-01 |
CARRIER-DECK, WING This part replaces 69-4400. Price: $2,088.97 |
| 55 |
69-1580-03 |
ANCHOR-LH This part replaces 69-1580. Price: $527.05 |
| 56 |
321-9 |
SCREW-HH Price: $0.27 |
| 57 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 58 |
328-24 |
SCREW-HH Price: $23.99 |
| 59 |
39-7650-01 |
COVER This part replaces 39-7650. Price: $14.67 |
| 60 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
