| Ref | Part Number | Description |
|---|
| 1 |
3-9034 |
DISCONTINUED Price: Call Us |
| 1 |
530071305 |
Kit-Trigger & Lockout Price: $4.99 |
| 2 |
322-9 |
SCREW-HH Price: $3.09 |
| 3 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 3 |
530016149 |
Spring-Switch Price: $1.99 |
| 4 |
3-7243 |
SPRING-EXTENSION Price: $11.23 |
| 4 |
530015775 |
Screw Price: $1.99 |
| 5 |
5-2907 |
DISCONTINUED Price: Call Us |
| 5 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 6 |
5-2916 |
DISCONTINUED Price: Call Us |
| 6 |
530023877 |
Fitting Price: $1.99 |
| 7 |
3272-13 |
PIN-COTTER This part replaces 3272-14. Price: $0.25 |
| 7 |
580940901 |
FUEL CAP ASSY This part replaces 530047192. Price: $3.99 |
| 8 |
3256-39 |
WASHER-FLAT Price: $1.29 |
| 8 |
530056402 |
Handle-Starter Price: $2.99 |
| 9 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 9 |
530069232 |
Kit-Rope Price: $3.99 |
| 10 |
5-2908 |
DISCONTINUED Price: Call Us |
| 10 |
530054175 |
Housing-Fan Price: $4.99 |
| 11 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 11 |
530015920 |
Screw Price: $1.99 |
| 12 |
282-2 |
YOKE Price: $30.04 |
| 12 |
530016134 |
Nut-Flywheel Price: $1.99 |
| 13 |
3290-212 |
WASHER-SPRING Price: $1.56 |
| 13 |
530015127 |
Washer-Flywheel Price: $1.99 |
| 14 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 14 |
530047534 |
FLYWHEEL ASSY This part replaces 530039187. Price: $22.99 |
| 15 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 15 |
530016133 |
Bolt-Bar Mounting Price: $1.99 |
| 16 |
530015922 |
Nut-Speed Price: $1.99 |
| 16 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 17 |
322-3 |
SCREW-HH Price: $0.79 |
| 17 |
530037809 |
Wire-Throttle Price: $1.99 |
| 18 |
3217-26 |
NUT-HEX Price: $0.25 |
| 18 |
530049005 |
Grommet-Choke Knob Price: $1.99 |
| 19 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 19 |
530047989 |
Lever-Choke Price: $1.99 |
| 20 |
3274-33 |
DISCONTINUED Price: Call Us |
| 21 |
5-3323 |
DISCONTINUED Price: Call Us |
| 21 |
530015907 |
Washer - Thrust Price: $1.99 |
| 22 |
530047061 |
Assy-Drum W/brg. Price: $11.99 |
| 23 |
323-39 |
SCREW-HH This part replaces 323-21. Price: $1.60 |
| 23 |
530015611 |
Washer-Clutch Price: $1.99 |
| 24 |
323-23 |
SCREW-HH Price: $2.07 |
| 24 |
530014949 |
Assy. - Clutch Price: $7.99 |
| 25 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 25 |
545139902 |
Assy-Chain Brake Price: $22.99 |
| 26 |
5-3900 |
Main Frame (Incl. Ref. 46) Price: Call Us |
| 26 |
530015917 |
Nut-Bar Mounting Price: $0.99 |
| 27 |
256-159 |
BUSHING Price: $24.63 |
| 27 |
530015826 |
Pin-Bar Adjust Price: $1.99 |
| 28 |
3-8775 |
DISCONTINUED Price: Call Us |
| 28 |
530038593 |
Retainer-Bar Adjust Price: $0.99 |
| 29 |
3-8778 |
DISCONTINUED Price: Call Us |
| 30 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 30 |
952044370 |
BAR 16" .050 3/8 .041 56DL Price: $24.99 |
| 31 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 31 |
581562201 |
ACCY P/PP CHN 16" 56DL 3/8 This part replaces 952051211. Price: $19.99 |
| 32 |
322-3 |
SCREW-HH Price: $0.79 |
| 32 |
530038238 |
Plate-Bar Mounting Price: $1.99 |
| 33 |
322-6 |
SCREW-HH Price: $0.45 |
| 33 |
530015814 |
Screw Price: $1.99 |
| 34 |
5-4403 |
DISCONTINUED Price: Call Us |
| 34 |
530029850 |
Chain Catcher Price: $1.99 |
| 35 |
3-9035 |
DISCONTINUED Price: Call Us |
| 35 |
530016132 |
Screw Price: $1.99 |
| 36 |
5-4401 |
DISCONTINUED Price: Call Us |
| 36 |
530057236 |
Assy-Oil Cap Price: $5.99 |
| 37 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 37 |
530071666 |
Kit-Oil Vent Price: $7.99 |
| 38 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 38 |
530016080 |
Screw Price: $1.99 |
| 39 |
217-34 |
BOLT WHEEL RETAINER Price: $13.47 |
| 39 |
545034301 |
STARTER PULLEY This part replaces 530037817. Price: $8.99 |
| 40 |
3212-2 |
SCREW-HH Price: $3.60 |
| 40 |
545008015 |
SPRING STARTER This part replaces 530027531. Price: $2.99 |
| 41 |
3254-20 |
WASHER-LOCK, INT This part replaces 3254-3. Price: $1.29 |
| 41 |
530015892 |
Screw Price: $1.99 |
| 42 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 42 |
530059173 |
Handle-Front This part replaces 530059172. Price: $17.99 |
| 43 |
3273-32 |
DISCONTINUED Price: Call Us |
| 43 |
530015814 |
Screw Price: $1.99 |
| 44 |
3-9274 |
SPACER Price: $6.33 |
| 44 |
530015940 |
Screw Price: $1.99 |
| 45 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 46 |
256-90 |
BUSHING-FLANGE Price: $2.92 |
| 46 |
530037820 |
Gear-Worm Spring Price: $1.99 |
| 47 |
5-1183 |
DISCONTINUED Price: Call Us |
| 47 |
530049477 |
Elbow-Oil Pickup Price: $1.99 |
| 48 |
3-8826 |
DISCONTINUED Price: Call Us |
| 48 |
545227101 |
SCREW 6-19X.437 This part replaces 530016064. Price: $1.99 |
| 49 |
3-8844 |
DISCONTINUED Price: Call Us |
| 49 |
530019206 |
Seal Block Price: $1.99 |
| 50 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 51 |
3212-2 |
SCREW-HH Price: $3.60 |
| 51 |
530038373 |
Pickup-Oiler Price: $1.99 |
| 52 |
3-8845 |
DISCONTINUED Price: Call Us |
| 53 |
3218-5 |
NUT-JAM Price: $0.27 |
| 54 |
5-4002 |
DISCONTINUED Price: Call Us |
| 55 |
5-2568 |
DISCONTINUED Price: Call Us |
| 56 |
325-13 |
SCREW-HH Price: $3.57 |
| 57 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 58 |
5-2667 |
DISCONTINUED Price: Call Us |
| 59 |
323-11 |
SCREW-HH Price: $1.08 |
| 60 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 61 |
5-2567 |
DISCONTINUED Price: Call Us |
| 62 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 63 |
3-8936 |
DISCONTINUED Price: Call Us |
| 64 |
3-9033 |
DISCONTINUED Price: Call Us |
| 65 |
3220-2 |
NUT-JAM Price: $0.50 |
| 66 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 67 |
23-4680 |
BRAKE BAND ASM This part replaces 5-2905. Price: $229.48 |
| 68 |
3273-30 |
DISCONTINUED Price: Call Us |
| 69 |
5-3314 |
Cable Guard Price: Call Us |
| 70 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 71 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 72 |
5-3910 |
DISCONTINUED Price: Call Us |
| 73 |
5-3913 |
DISCONTINUED Price: Call Us |
