| Ref | Part Number | Description |
|---|
| 1 |
57-8800 |
INLET ASM Price: $71.04 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 2 |
59-0690 |
DISCONTINUED Price: Call Us |
| 3 |
59-0940 |
DISCONTINUED Price: Call Us |
| 4 |
3253-2 |
WASHER-LOCK Price: $0.25 |
| 5 |
57-8720 |
ADAPTER Price: $232.98 |
| 6 |
57-9620 |
SEAL Price: $5.93 |
| 7 |
71-6210 |
PLUG, HOLE Price: $23.20 |
| 8 |
72-3890 |
SCREW Price: $2.29 |
| 9 |
57-9170 |
SWIVEL Price: $26.27 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
59-0460 |
SWIVEL-CHOKE Price: $20.24 |
| 11 |
583389701 |
KIT.SVC.CLUTCH.ELE.180505 This part replaces 532180505. Price: $299.99 |
| 11 |
59-0580 |
DISCONTINUED Price: Call Us |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 12 |
59-0720 |
PIN-COTTER Price: $5.60 |
| 13 |
59-0470 |
BRACKET Price: $13.60 |
| 14 |
72-3880 |
SCREW-HWH Price: $4.14 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 15 |
57-9190 |
CLIP Price: $5.22 |
| 16 |
72-3900 |
SCREW-TAPPING Price: $5.90 |
| 17 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 18 |
57-9180 |
LINK-CHOKE Price: $16.40 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532430217. Price: $14.99 |
| 19 |
59-1020 |
BOLT-SHOULDER Price: $7.83 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 20 |
82-0530 |
DISCONTINUED Price: Call Us |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 21 |
82-0540 |
TUBE-BREATHER Price: $68.03 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 22 |
57-9540 |
DISCONTINUED Price: Call Us |
| 23 |
71-6130 |
DISCONTINUED Price: Call Us |
| 24 |
82-0560 |
DISCONTINUED Price: Call Us |
| 25 |
57-8580 |
FILTER Price: $4.56 |
| 26 |
82-0570 |
SEAL - O-RING Price: $12.69 |
| 27 |
82-1480 |
SCREW-TAPPING, ROUND HEAD Price: $2.69 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 70 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 This part replaces 532146699. Price: $19.99 |
| 71 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 This part replaces 532146700. Price: $17.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
