| Ref | Part Number | Description |
|---|
| 1 |
532184233 |
DECK.SVC.4.GA.WHLS.48".BLK This part replaces 532183389. Price: $349.99 |
| 1 |
67-4400 |
BOLT Price: $3.16 |
| 3 |
531165401 |
SERVICE.KIT BRACKET BRKT ASM S This part replaces 532138017. Price: $12.99 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 5 |
94-3533 |
COVER ASM - INLET Price: $262.23 |
| 6 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532178024. Price: $9.99 |
| 6 |
92-0846 |
DISCONTINUED Price: Call Us |
| 7 |
42-9430 |
SCREW-HH Price: $0.30 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 532174365. Price: $6.99 |
| 8 |
67-2670 |
DISCONTINUED Price: Call Us |
| 9 |
42-7510 |
DISCONTINUED Price: Call Us |
| 11 |
93-3444 |
CAP-FILLER This part replaces 92-0847. Price: $45.82 |
| 12 |
67-2770 |
DISCONTINUED Price: Call Us |
| 13 |
532175147 |
SHAFT, ASM. MANDEREL SEALED Price: $24.99 |
| 13 |
67-2780 |
WASHER Price: $1.35 |
| 14 |
532174358 |
HOUSING, MANDREL 48" Price: $49.99 |
| 14 |
67-2760 |
GASKET Price: $25.95 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 15 |
67-2740 |
FLANGE BOLT Price: $7.07 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 16 |
67-2680 |
ENGINE HANGER Price: $9.36 |
| 17 |
596987501 |
Bolts This part replaces 872110610. Price: $3.99 |
| 17 |
67-2340 |
BOLT W/WASHER Price: $2.19 |
| 18 |
56-0020 |
EXPANSION PLUG Price: $14.38 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 19 |
86-6240 |
PLUG-TAPERED This part replaces 67-2570. Price: $5.11 |
| 20 |
42-9570 |
STUD Price: $2.57 |
| 20 |
531167501 |
SERVICE KIT BAFFLE BAFFLE This part replaces 532174378. Price: $12.99 |
| 21 |
42-9110 |
GASKET Price: $29.21 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
67-4580 |
BOLT Price: $2.94 |
| 23 |
60-7370 |
BOLT This part replaces 67-4590. Price: $2.75 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 24 |
67-4560 |
DISCONTINUED Price: Call Us |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 25 |
94-1258 |
GASKET - CYL HEAD Price: $209.59 |
| 26 |
112-8435 |
GASKET-EXHAUST MANIFOLD This part replaces 67-4570. Price: $9.18 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
532180655 |
DEFLECTOR.ASM.BLACK.48" This part replaces 532181707. Price: $39.99 |
| 27 |
67-4700 |
GLOW LAMP Price: $117.35 |
| 28 |
75-4930 |
DISCONTINUED Price: Call Us |
| 28 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: $5.99 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 29 |
93-3526 |
SWITCH This part replaces 67-4500. Price: $177.42 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 30 |
93-3527 |
GASKET This part replaces 67-4490. Price: $4.82 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 31 |
67-4460 |
GASKET-FITTING, THERMOSTAT Price: $4.73 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532177865. Price: $14.99 |
| 32 |
67-4450 |
FITTING-THERMOSTAT Price: $266.48 |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 33 |
67-4470 |
DISCONTINUED Price: Call Us |
| 34 |
67-2330 |
BOLT Price: $2.25 |
| 35 |
67-4510 |
GUAGE-TEMP, WATER Price: $151.90 |
| 36 |
43-2710 |
O-RING Price: $6.47 |
| 36 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 37 |
532177968 |
PULLEY.IDLER.FLAT Price: $27.99 |
| 37 |
67-4480 |
BY-PASS PIPE Price: $15.39 |
| 38 |
67-4440 |
THERMOSTAT Price: $87.79 |
| 39 |
532174375 |
PULLEY.DRIVEN.DECK.48' Price: $34.99 |
| 39 |
67-4680 |
GLOW PLUG Price: $56.05 |
| 40 |
67-4690 |
GLOW PLUG PLATE Price: $11.69 |
| 41 |
99-1801 |
CAP - SEALING (DIA 20) This part replaces 67-2710. Price: $13.58 |
| 42 |
532165723 |
SPACER.RETAINER.MOWER Price: $5.99 |
| 42 |
67-2700 |
VALVE GUIDE Price: $30.99 |
| 43 |
532174373 |
ARM, IDLER SECONDARY Price: $9.99 |
| 43 |
67-2730 |
BOLT Price: $13.81 |
| 44 |
67-4550 |
INTAKE MANIFOLD GASKET Price: $15.80 |
| 45 |
532180806 |
COVER.MANDREL.DECK.48" Price: $12.99 |
| 45 |
67-4430 |
GASKET-FITTING, WATER OUTLET Price: $4.75 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 46 |
67-4420 |
DISCONTINUED Price: Call Us |
| 47 |
532180808 |
V-BELT, 48"SECONDARY Price: $49.99 |
| 48 |
532174368 |
V-BELT PRIMARY 48" Price: $49.99 |
| 49 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 50 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 52 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 54 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 55 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 56 |
532155986 |
BAR.ADJUST.WHEEL.ANTI.SCALP.BL Price: $17.99 |
| 57 |
532156941 |
RIVET.PIN.HEAD.YELLOW. Price: $4.99 |
| 72 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 91 |
529846201 |
SERVICE KIT BRKT.NOSEROLLER.RH This part replaces 532180535. Price: $5.99 |
| 92 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 94 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 95 |
529846101 |
SERVICE KIT BRKT.NOSEROLLER.LH This part replaces 532180534. Price: $5.99 |
| 97 |
532178515 |
WASHER Price: $5.99 |
| 98 |
532179479 |
SPRING PRIMARY DRIVE Price: $3.99 |
| 99 |
532193195 |
PULLEY.V.IDLER This part replaces 532184058. Price: $49.99 |
| 100 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 110 |
532175016 |
ARM, SPRING SECONDARY Price: $4.99 |
| 111 |
532174610 |
ARM SPRING FIXED TENSION Price: $6.99 |
| 116 |
596434404 |
Bolts This part replaces 532184219. Price: $4.99 |
| 117 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 121 |
532174371 |
SPRING.DRIVE.SECONDARY.48".DEC Price: $5.99 |
| 126 |
532174372 |
ARM, IDLER PRIMARY DECK Price: $9.99 |
| 130 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 131 |
819131606 |
Washer 13/32 x 1 x 6 Ga. Price: $4.99 |
| 132 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 133 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 182 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 183 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 184 |
532173979 |
KEEPER BELT IDLER PLATED Price: $4.99 |
