| Ref | Part Number | Description |
|---|
| 1 |
163465 |
Battery Price: Call Us |
| 2 |
74760412 |
Bolt Hex Head 1/4-20 x 3/4 Price: Call Us |
| 8 |
186491 |
Box Battery Price: Call Us |
| 10 |
98-9678 |
IDLE APPARATUS ASM Price: $43.48 |
| 16 |
176138 |
Switch Interlock Push-In Price: Call Us |
| 20 |
112-7014 |
ADJUSTING BOLT ASM This part replaces 98-9679. Price: $14.56 |
| 21 |
175688 |
Harness Socket Light w/4152J Price: Call Us |
| 22 |
4152J |
Bulb Light Price: Call Us |
| 24 |
400253 |
Cable Battery Price: Call Us |
| 25 |
198893 |
Cable Starter Price: Call Us |
| 26 |
175158 |
Fuse Price: Call Us |
| 27 |
73510400 |
Nut Keps. Hex 1/4-20 unc Price: Call Us |
| 28 |
145491 |
Cable, Ground Price: Call Us |
| 29 |
401545 |
Switch, Seat Price: Call Us |
| 30 |
193350 |
Switch, Ign. Price: Call Us |
| 30 |
98-9439 |
NUT Price: $0.74 |
| 33 |
411935 |
Key/Chain Price: Call Us |
| 34 |
110712X |
Switch Light/Reset Price: Call Us |
| 40 |
401104 |
Harness Ign. Dash Price: Call Us |
| 40 |
99-8387 |
NUT-CAP Price: $2.74 |
| 41 |
17720408 |
Screw Thd. Cut 1/4-20 x 1/2 Price: Call Us |
| 42 |
131563 |
Cover, Terminal Price: Call Us |
| 43 |
192507 |
Solenoid Price: Call Us |
| 46 |
401763 |
Gauge Hourmeter Price: Call Us |
| 50 |
174653 |
Switch PTO Price: Call Us |
| 50 |
98-7654 |
GASKET Price: $8.84 |
| 55 |
17490512 |
Screw Thdrol. 5/16-18 x 3/4 TYTT Price: Call Us |
| 60 |
98-7656 |
CAP Price: $7.29 |
| 70 |
112-7015 |
BOLT-ADJUSTING This part replaces 98-9557. Price: $6.24 |
| 71 |
194276 |
Harness Chassis Price: Call Us |
| 79 |
175242 |
Socket Asm. Bulb Twistlock Price: Call Us |
| 80 |
99-3512 |
NUT Price: $4.75 |
| 90 |
400724 |
Cover Terminal Battery Price: Call Us |
| 90 |
99-8387 |
NUT-CAP Price: $2.74 |
| 91 |
190270 |
Strap Battery Mount Front Price: Call Us |
| 99 |
17670412 |
Screw Hex Wsh. Thdrol. 1/4-20 x 3/4 Price: Call Us |
| 100 |
19091416 |
Washer 9/32 x 7/8 x 16 Ga. Price: Call Us |
| 100 |
98-7654 |
GASKET Price: $8.84 |
| 101 |
198317 |
Pigtail Price: Call Us |
| 102 |
404454 |
Harness Pigtail K46 TEX ROS Price: Call Us |
| 110 |
107-9081 |
GASKET Price: $3.94 |
| 130 |
104-5155 |
SOLENOID-STOP Price: $244.96 |
| 140 |
105-3799 |
BOLT-HSH Price: $0.84 |
| 150 |
98-7699 |
WASHER-SPRING Price: $0.44 |
| 160 |
99-3514 |
COVER Price: $11.33 |
| 170 |
98-9636 |
GASKET-PUMP, FUEL Price: $2.58 |
| 180 |
98-7572 |
NUT Price: $0.32 |
| 190 |
98-7699 |
WASHER-SPRING Price: $0.44 |
