| Ref | Part Number | Description |
|---|
| 1 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 1 |
532006554 |
TINE.LH.12" This part replaces 532004459. Price: $11.99 |
| 2 |
532132673 |
Clevis Pin Price: $1.99 |
| 2 |
69-5510 |
HOSE ASM Price: $77.25 |
| 3 |
323-6 |
SCREW-HH Price: $0.66 |
| 3 |
532006554 |
Tine, Inner, L.H. Price: $11.99 |
| 4 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 4 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $1.99 |
| 5 |
532132727 |
Assembly, Hub and Plate, L.H. Price: $61.99 |
| 5 |
71-2590 |
SHAFT-PIVOT Price: $228.41 |
| 6 |
69-7960-01 |
SUPPORT-AXLE Price: $461.54 |
| 6 |
873680600 |
Nut This part replaces 873610600. Price: $1.99 |
| 7 |
539990118 |
WASHER.3/8 This part replaces 810040600. Price: $1.49 |
| 7 |
98-1452 |
WASHER-THRUST Price: $0.94 |
| 8 |
100-3364-01 |
REAR AXLE ASM Price: $951.06 |
| 8 |
874610616 |
Bolt, Hex 3/8-24 x 1 Price: $3.99 |
| 9 |
532006555 |
TINE.RH.12"(72R) This part replaces 532004460. Price: $14.99 |
| 10 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 10 |
532132728 |
Assembly, Hub and Plate, R.H. Price: $59.99 |
| 11 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 12 |
100-3362 |
CAP-SPINDLE Price: $44.10 |
| 13 |
100-4196 |
RING-RETAINING Price: $1.90 |
| 16 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 18 |
106-6895-03 |
BALL JOINT ASM Price: $258.08 |
| 25 |
69-9870 |
WIDE WHEEL AND 6-PLY TIRE ASM Price: $513.71 |
| 30 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 31 |
132-1308 |
HYD CYLINDER ASM This part replaces 98-0661. Price: $813.52 |
| 32 |
32136-13 |
NUT-SHH Price: $2.85 |
| 33 |
100-6116 |
SCREW-HHF Price: $6.41 |
| 34 |
32128-23 |
NUT-HF Price: $1.51 |
| 35 |
3290-216 |
WASHER Price: $3.83 |
| 36 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 37 |
110-6143-01 |
TIE ROD ASM Price: $513.93 |
| 38 |
340-70 |
NUT-LOCK Price: $2.10 |
| 39 |
95-6487-03 |
BRACKET-HOSE Price: $87.30 |
| 40 |
69-6010 |
TUBE-HYD Price: $162.05 |
| 41 |
69-6020 |
TUBE-HYD Price: $138.98 |
| 43 |
32152-5 |
NUT-HEX Price: $0.54 |
