| Ref | Part Number | Description |
|---|
| 1 |
532429667 |
KIT.CONTROL.SPEED.SELECTOR.SNO This part replaces 532198474. Price: $74.99 |
| 1 |
98-9517 |
BOLT-ROD, CONNECTING Price: $10.31 |
| 2 |
117-7588 |
METAL-CRANKPIN (-0.4MM) This part replaces 98-9520. Price: $49.06 |
| 2 |
817501010 |
SCREW #10-24 X 5/8 Price: $4.99 |
| 2 |
98-9519 |
BEARING-ROD (-0.2MM) Price: $43.73 |
| 2 |
98-9553 |
BEARING-ROD (STD) This part replaces 98-9518. Price: $52.92 |
| 3 |
115-3014 |
BUSHING-PIN, PISTON This part replaces 98-9515. Price: $19.81 |
| 3 |
532197763 |
DRIVE PLATE WELDMENT Price: $54.99 |
| 4 |
532197764 |
SHAFT.HEX.SHORT Price: $11.99 |
| 4 |
98-9514 |
CIRCLIP-PIN, PISTON Price: $2.79 |
| 5 |
597412801 |
BEARING HOUSING ASSY TRUNNION This part replaces 532175344. Price: $29.99 |
| 5 |
98-9513 |
PIN-PISTON Price: $13.17 |
| 6 |
583607301 |
RING.RETAINING. This part replaces 812000012. Price: $2.99 |
| 6 |
98-9618 |
PISTON RING ASM (STD) Price: $102.14 |
| 6 |
98-9619 |
PISTON RING ASM (0.5MM) Price: $96.35 |
| 7 |
112-8415 |
PISTON ASM This part replaces 98-9470. Price: $456.30 |
| 7 |
115-4127 |
PISTON KIT This part replaces 98-9469. Price: $518.71 |
| 7 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872270505. Price: $2.99 |
| 8 |
532188909 |
BEARING FLANGE Price: $24.99 |
| 8 |
98-9542 |
GEAR-DRIVE, OIL PUMP Price: $89.04 |
| 9 |
532182504 |
SPACER, BEARING Price: $5.99 |
| 9 |
98-9532 |
GEAR-CRANKSHAFT Price: $169.43 |
| 10 |
532184077 |
LEVER.SHIFTER.PLATE.BLACK Price: $9.99 |
| 10 |
98-9666 |
KEY Price: $3.58 |
| 11 |
110-3729 |
BALL This part replaces 98-7473. Price: $0.69 |
| 11 |
532175349 |
BRACKET, SHIFTER SUPPORT This part replaces 532184076. Price: $4.99 |
| 12 |
532178695 |
PIN, PIVOT LEVER Price: $4.99 |
| 12 |
98-9375 |
PIN-STRAIGHT Price: $0.41 |
| 13 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 13 |
98-9522 |
SLEEVE-CRANKSHAFT Price: $116.47 |
| 14 |
127-0416 |
METAL-SIDE (+0.2MM) This part replaces 98-9414. Price: $21.04 |
| 14 |
596437001 |
Screws This part replaces 817490408. Price: $2.99 |
| 14 |
98-9413 |
BEARING-THRUST (STD) Price: $16.90 |
| 14 |
98-9415 |
BEARING-THRUST (0.4MM) Price: $9.77 |
| 15 |
127-0437 |
METAL-SIDE (+0.2MM) This part replaces 98-9689. Price: $18.42 |
| 15 |
127-0438 |
METAL-SIDE (+0.40MM) This part replaces 98-9690. Price: $12.65 |
| 15 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 15 |
98-9688 |
BEARING-THRUST (STD) Price: $16.90 |
| 16 |
115-4121 |
METAL-CRANKSHAFT (STD) This part replaces 98-9525. Price: $86.06 |
| 16 |
532184075 |
PLATE.DRIVE.MOUNTING.BLACK Price: $14.99 |
| 16 |
98-9526 |
BEARING-MAIN (0.2MM) Price: $64.36 |
| 16 |
98-9527 |
BEARING-MAIN (0.4MM) Price: $63.74 |
| 17 |
127-0433 |
METAL-CRANKSHAFT (-0.2MM) This part replaces 98-9530. Price: $60.46 |
| 17 |
596039201 |
GSPW Hardware This part replaces 532155377. Price: $2.99 |
| 17 |
98-9524 |
METAL-CRANKSHAFT (STD SET) Price: $62.26 |
| 17 |
98-9531 |
BEARING-MAIN (0.4MM) Price: $39.97 |
| 18 |
112-7005 |
BEARING-MAIN (STD) This part replaces 98-9523. Price: $66.99 |
| 18 |
532191080 |
PULLEY.TRACTION.7.75 Price: $49.99 |
| 18 |
98-9528 |
BEARING-MAIN (-0.2MM) Price: $15.04 |
| 18 |
98-9529 |
BEARING-MAIN (0.4MM) Price: $40.04 |
| 19 |
819111507 |
WASHER, FLAT Price: $4.99 |
| 19 |
98-9373 |
O-RING Price: $3.11 |
| 20 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 20 |
98-9521 |
COLLAR-CRANKSHAFT Price: $84.21 |
| 21 |
117-7586 |
CONNECTING ROD ASM This part replaces 98-9516. Price: $547.99 |
| 21 |
874950512 |
SCREW 5/16--18 X .750 Price: $3.99 |
| 22 |
532422111 |
ARM.IDLER.BRAKE.BLACK Price: $12.99 |
| 23 |
594095301 |
Pulleys This part replaces 532180523. Price: $9.99 |
| 24 |
532422762 |
KIT.SERVCE.IDLER.PULLEY This part replaces 532184074. Price: $79.99 |
| 25 |
532175330 |
PIN, IDLER PIVOT Price: $4.99 |
| 26 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 27 |
585802801 |
NUT.HEX.FL 5/16-18 TOP LCK BLK This part replaces 532166785. Price: $4.99 |
| 28 |
532414557 |
SPRING.TRACTION.IDLER This part replaces 532181044. Price: $4.99 |
| 29 |
585238401 |
ARM.ASM.TRACTION.IDLER. This part replaces 532179354. Price: $27.99 |
| 30 |
532180522 |
PULLEY.W/SPACER.2.25 Price: $22.99 |
| 31 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 32 |
532059289 |
STEEL WASHER Price: $3.99 |
| 33 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 34 |
874550520 |
SCREW 3/8--24 X 1.38 Price: Call Us |
| 35 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 36 |
819112206 |
WASHER.FLAT.34X1.38X22 Price: $4.99 |
| 37 |
595926601 |
PULLEY This part replaces 532180478. Price: $27.99 |
| 38 |
532409475 |
SPACER.ENGINE.PULLEY Price: $7.99 |
| 39 |
532179095 |
SPRING.RETURN Price: $3.99 |
| 40 |
532155452 |
BELT.GUIDE.RH Price: $4.99 |
| 41 |
874610516 |
SCREW Price: $3.99 |
| 42 |
587343701 |
BUSHING.BRAKE.ARM This part replaces 532175331. Price: $5.99 |
| 43 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 811050500. Price: $2.99 |
