CONTROLS
Parts (107)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 120-3801-03 | FRAME-ARM, CONTROL Price: $445.78 |
| 1 | 544255101 | HANDLE ASSY Price: $44.99 |
| 2 | 120-6310 | LCD DISPLAY ASM Price: $584.72 |
| 2 | 506597401 | BOLT Price: $5.99 |
| 3 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 3 | 95-8999 | SWITCH Price: $42.14 |
| 4 | 105-4232 | SWITCH Price: $88.64 |
| 4 | 544290001 | NEEDS DESCRIPTION Price: Call Us |
| 5 | 32144-86 | SCREW-HWHTF Price: $1.29 |
| 5 | 725246251 | SCREW Price: $4.99 |
| 6 | 3230-23 | SCREW-CARR Price: $0.89 |
| 6 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 7 | 125-1938 | LATCH Price: $27.46 |
| 7 | 544288801 | NEEDS DESCRIPTION Price: Call Us |
| 8 | 120-5280 | BRACKET-JOYSTICK Price: $203.76 |
| 8 | 544289401 | NEEDS DESCRIPTION Price: Call Us |
| 9 | 104-7201 | NUT-HF Price: $0.69 |
| 9 | 535479901 | NEEDS DESCRIPTION Price: Call Us |
| 10 | 3258-166 | SCREW-PRH Price: $0.28 |
| 10 | 721430970 | NEEDS DESCRIPTION Price: Call Us |
| 11 | 586966401 | PEDAL RUBBER This part replaces 506506201. Price: $14.99 |
| 11 | 74-5950 | LATCH-SWELL Price: $21.28 |
| 12 | 104-2065 | SCREW-HWH Price: $0.28 |
| 12 | 535459901 | ROLLER Price: $15.99 |
| 13 | 256-257 | BUSHING-NYLINER Price: $3.19 |
| 13 | 544289101 | NEEDS DESCRIPTION Price: Call Us |
| 14 | 104-8300 | NUT-HF, NI Price: $0.39 |
| 14 | 727645951 | Screw Mvbf 8 X 40 Price: $2.28 |
| 15 | 108-7605 | COVER-RH Price: $55.56 |
| 15 | 535459501 | SPRING Price: $7.99 |
| 16 | 108-7604 | COVER-LH Price: $55.56 |
| 16 | 506954101 | SUPPORT Price: $5.99 |
| 17 | 233-42 | KNOB Price: $12.88 |
| 17 | 506804101 | PLATE Price: $5.99 |
| 18 | 732211801 | LOCKNUT M8 This part replaces 731211801. Price: $3.99 |
| 18 | 93-5961 | BOOT-LEVER Price: $56.35 |
| 19 | 112-9181 | PLATE-BOOT Price: $4.90 |
| 19 | 544338201 | NEEDS DESCRIPTION Price: Call Us |
| 20 | 161-7350 | IGNITION SWITCH ASM This part replaces 106-5269. Price: $56.32 |
| 20 | 725245951 | SCREW Price: $4.99 |
| 21 | 125-8754 | DECAL-PANEL, CONTROL Price: $30.81 |
| 21 | 734116401 | WASHER BRB 8.4X17 Price: $5.99 |
| 22 | 120-4158 | DECAL-CONSOLE, UPPER Price: $23.98 |
| 22 | 506814909 | NEEDS DESCRIPTION Price: Call Us |
| 23 | 3296-2 | NUT-LOCK, NI Price: $1.89 |
| 23 | 506789901 | LINK Price: $89.99 |
| 24 | 506897601 | NUT Price: $3.99 |
| 25 | 732212001 | NUT This part replaces 732212051. Price: $3.99 |
| 26 | 506951701 | LINK Price: $39.99 |
| 27 | 725249571 | SCREW Price: $6.99 |
| 27 | 99-8970 | KEY-LATCH, HOOD Price: $15.13 |
| 28 | 3250-22 | SCREW-PPH Price: $4.09 |
| 28 | 732212001 | NUT This part replaces 732212051. Price: $3.99 |
| 29 | 114-0446 | PANEL-ACCESS Price: $18.13 |
| 29 | 505149201 | NEEDS DESCRIPTION Price: Call Us |
| 30 | 117-0169 | DECAL-FUSES Price: $17.49 |
| 30 | 505149501 | NEEDS DESCRIPTION Price: Call Us |
| 31 | 114-3321 | CONTROLLER-TEC Price: $1,515.96 |
| 31 | 725246351 | SCREW This part replaces 725246071. Price: $4.99 |
| 32 | 32144-87 | SCREW-HWHTF Price: $0.49 |
| 32 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 33 | 108-7602 | REST-ARM Price: $158.43 |
| 33 | 725245371 | SCREW This part replaces 725245351. Price: $4.99 |
| 34 | 110-8912 | SEAL-FOAM Price: $2.23 |
| 35 | 110-5331 | SPRING-COMPRESSION Price: $22.18 |
| 36 | 283-88 | PIN-CLEVIS Price: $5.77 |
| 37 | 32144-41 | SCREW-TAPTITE Price: $4.79 |
| 38 | 4-2390 | WASHER-FLAT Price: $0.62 |
| 39 | 110-5313-03 | BRACKET-RETAINER Price: $35.01 |
| 40 | 283-73 | PIN-CLEVIS Price: $0.95 |
| 41 | 322-7 | SCREW-HH Price: $0.89 |
| 42 | 110-5314 | LATCH Price: $22.89 |
| 43 | 3272-1 | PIN-COTTER Price: $0.25 |
| 44 | 110-8856 | SPACER Price: $10.25 |
| 45 | 3256-23 | WASHER-PLAIN Price: $0.28 |
| 46 | 3272-10 | PIN-COTTER Price: $0.25 |
| 47 | 544357601 | NEEDS DESCRIPTION Price: Call Us |
| 48 | 544357602 | NEEDS DESCRIPTION Price: Call Us |
| 49 | 506946301 | SPRING Price: $7.99 |
| 50 | 725246351 | SCREW This part replaces 725246071. Price: $4.99 |
| 51 | 506542501 | SPRING Price: $6.99 |
| 55 | 535475245 | Screws Price: $2.99 |
| 56 | 732211601 | LOCKNUT M6 Price: $4.99 |
| 59 | 522454201 | NEEDS DESCRIPTION Price: Call Us |
| 66 | 725236851 | Screw Price: $1.32 |
| 67 | 732211601 | LOCKNUT M6 Price: $4.99 |
| 68 | 734181251 | WASHER This part replaces 734115601. Price: $0.99 |
| 75 | 521902701 | NEEDS DESCRIPTION Price: Call Us |
| 77 | 544290301 | LINK Price: $11.99 |
| 79 | 506986102 | BUSHING This part replaces 506986101. Price: $14.99 |
| 80 | 544279401 | SLEEVE Price: $17.99 |
| 81 | 725254351 | NEEDS DESCRIPTION Price: Call Us |
| 82 | 732252201 | Nut Price: $2.65 |
| 83 | 734118041 | NEEDS DESCRIPTION Price: Call Us |
| 84 | 725233151 | SCREW M6S 5X20 Price: $2.99 |
| 85 | 732211401 | LOCKNUT M5 Price: $2.99 |
| 86 | 725254351 | NEEDS DESCRIPTION Price: Call Us |
| 87 | 521903101 | NEEDS DESCRIPTION Price: Call Us |
| 88 | 521902901 | NEEDS DESCRIPTION Price: Call Us |
| 89 | 521903501 | NEEDS DESCRIPTION Price: Call Us |
| 90 | 521903601 | NEEDS DESCRIPTION Price: Call Us |
| 91 | 506597401 | BOLT Price: $5.99 |
| 92 | 732211801 | LOCKNUT M8 Price: $3.99 |
| 93 | 731231601 | NUT Price: $2.99 |
| 94 | 535429101 | NUT Price: $2.99 |
| 95 | 731231601 | NUT Price: $2.99 |
| 96 | 725237271 | SCREW Price: $3.99 |
