| Ref | Part Number | Description |
|---|
| 1 |
532429294 |
HEATER.BOX.ASSY-SNW(SKSN4100) Price: $89.99 |
| 1 |
67-3160 |
ROCKER ARM Price: $85.24 |
| 2 |
67-3230 |
DISCONTINUED Price: Call Us |
| 3 |
532429208 |
MUFFLER.ASSY.SNOW(SKSN4200) Price: $109.99 |
| 3 |
67-3240 |
SNAP RING Price: $0.87 |
| 4 |
532429209 |
FUEL.TANK.ASSY.SNOW(SKSN4300) Price: $169.99 |
| 4 |
67-3210 |
ADJUSTING SCREW Price: $10.58 |
| 5 |
532424942 |
FUEL CAP OVERSIZED CLICK STYLE This part replaces 532429211. Price: $14.99 |
| 5 |
67-3150 |
PUSH ROD Price: $16.61 |
| 6 |
585020406 |
CARB.ASSY.W/O.SPACER.LCT.414CC This part replaces 532429295. Price: $119.99 |
| 6 |
67-3120 |
TAPPET Price: $39.70 |
| 7 |
67-2910 |
GEAR Price: $205.68 |
| 8 |
595079601 |
PRIMER BULB.W/HOSE.LCT. This part replaces 532429218. Price: $8.99 |
| 8 |
75-5010 |
BRG SET STD - CONN ROD Price: $93.75 |
| 9 |
67-2850 |
CONNECTING ROD ASSEMBLY Price: $282.63 |
| 10 |
532429297 |
ELEC.START.ASSY.SNOW(SKSN4400) Price: $299.99 |
| 10 |
75-5080 |
PISTON & PIN SET - STD Price: $332.33 |
| 10A |
532437465 |
STARTER EUROPEAN 230V ELECTRIC Price: $449.99 |
| 11 |
532429221 |
KEY.SWITCH.ASSY.SNOW(SKSN4401) Price: $22.99 |
| 11 |
75-5050 |
RING SET - PISTON STD Price: $160.77 |
| 12 |
532429222 |
CDI.BOX.ASSY.SNOW(SKSN4404) Price: $11.99 |
| 12 |
67-2860 |
BOLT Price: $10.69 |
| 13 |
532429223 |
ON/OFF.SWITCH.SNOW(SKSN4403) Price: $14.99 |
| 13 |
67-2970 |
FLYWHEEL ASSY Price: $1,494.72 |
| 14 |
67-2990 |
DISCONTINUED Price: Call Us |
| 15 |
532429224 |
CHOKE.KNOW.SNOW(SKSN4500) Price: $7.99 |
| 15 |
67-2980 |
RING GEAR Price: $393.68 |
| 16 |
532429298 |
PLATE.GOVERN.LINK.S Price: $12.99 |
| 16 |
92-0845 |
CRANKSHAFT This part replaces 67-2920. Price: $3,048.45 |
| 17 |
42-9590 |
CONN ROD NUT Price: $10.19 |
| 17 |
582621602 |
RECOIL STARTER KIT This part replaces 532429299. Price: $99.99 |
| 18 |
532429300 |
STARTER.CUP.SML.SNOW(SKSN4601) Price: $11.99 |
| 18 |
56-0480 |
WOODRUFF KEY Price: $3.88 |
| 19 |
532443899 |
HANDLE.RECOIL.DELUXE.LCT This part replaces 532429301. Price: $14.99 |
| 19 |
67-2930 |
CRANKSHAFT PULLEY Price: $752.90 |
| 20 |
532429302 |
BLOWER.HSG.ASSY.ELEC(SKSN4602 Price: $39.99 |
| 20 |
67-2950 |
DISCONTINUED Price: Call Us |
| 21 |
532429231 |
SHIELD.CYLINDER.SNOW(SK4141010 Price: $3.99 |
| 21 |
67-2960 |
LOCKWASHER Price: $1.16 |
| 22 |
532429232 |
SHIELD.U/FYWHL.CHARG(SKSN4604) Price: $4.99 |
| 22 |
67-2940 |
DISCONTINUED Price: Call Us |
| 23 |
532429303 |
VALVE.COVER.LCT.414CC. Price: $27.99 |
| 23 |
67-4160 |
GASKET This part replaces 67-4310. Price: $4.78 |
| 24 |
75-5110 |
DISCONTINUED Price: Call Us |
| 25 |
42-9440 |
BOLT/WASHER Price: $4.52 |
| 25 |
532429234 |
FUEL.PETCOCK.SNOW(SKSN4900) Price: $14.99 |
| 26 |
532429304 |
FLYWHEEL.ASSY.ELEC.START Price: $149.99 |
| 26A |
532429305 |
FLYWHEEL.ASSY.MAN.START Price: $69.99 |
| 27 |
532429237 |
HIGHOIL.FILL.ASSY.KIT(SKSN4911 Price: $8.99 |
| 28 |
532429306 |
FLYWHEEL.FAN(SK4144000) Price: $29.99 |
| 28 |
67-3130 |
INTAKE VALVE Price: $61.71 |
| 29 |
532429307 |
IGNITION.COIL.ASSY This part replaces 532429610. Price: $49.99 |
| 29 |
67-3140 |
EXHAUST VALVE Price: $61.97 |
| 29A |
532443944 |
IGNITION.COIL.(CDI).291-414CC Price: $54.99 |
| 30 |
532429308 |
CRANKCASE.CVR.ASSY(SK4143600) Price: $119.99 |
| 30 |
92-1961 |
VALVE SEAL This part replaces 42-7870. Price: $14.93 |
| 31 |
532435534 |
DIPSTK.OIL.BLK.LCTSK4143711.1 Price: $9.99 |
| 31 |
67-3110 |
SPRING Price: $7.88 |
| 32 |
532429243 |
CHARGING.COIL.AC/DC(SK4141710) Price: $39.99 |
| 32 |
67-3100 |
RETAINER Price: $7.92 |
| 33 |
42-7860 |
RET LOCK MD 016483 Price: $8.42 |
| 33 |
532429290 |
ELECTRIC.START.BRKT(SKSN4405) Price: $11.99 |
| 34 |
532436966 |
SPARK.PLUG.BOOT.SNW,SKSN4691.1 Price: $14.99 |
| 34 |
67-3180 |
CAP Price: $9.39 |
| 35 |
67-3200 |
ROCKER STAY Price: $31.11 |
| 36 |
532429310 |
GOVERNOR.ARM.ASSY(SKSN4502) Price: $7.99 |
| 37 |
532429311 |
GOVERNOR.SHAFT(SK4143100) Price: $6.99 |
| 37 |
67-3220 |
PIN Price: $1.13 |
| 38 |
532429312 |
GOVERNOR.GEAR.ASSY(SK4142900) Price: $17.99 |
| 38 |
67-3190 |
DISCONTINUED Price: Call Us |
| 39 |
42-9660 |
WASHER Price: $2.50 |
| 39 |
532429313 |
CAMSHAFT(SK4141600) Price: $69.99 |
| 40 |
532429605 |
CYL.HEAD.ASSY.45 DEG.NON-GEN Price: $279.99 |
| 40 |
67-3170 |
SPRING Price: $2.87 |
| 41 |
532424939 |
SPARK.PLUG(2083810) This part replaces 532429255. Price: $14.99 |
| 41 |
67-3260 |
WASHER Price: $1.58 |
| 42 |
33114-060 |
SCREW-HH This part replaces 42-9510. Price: $0.88 |
| 42 |
532429257 |
CDI.BOX.BRKT.SNOW(SKSN4402) Price: $4.99 |
| 43 |
67-3250 |
ROCKER STRAY BOLT Price: $9.00 |
| 44 |
43-3160 |
ADJ SCREW MM 409167 Price: $2.18 |
| 44 |
532429315 |
PISTON.AND.ROD.ASSY(SK4141400) Price: $149.99 |
| 45 |
75-5120 |
DISCONTINUED Price: Call Us |
| 46 |
43-5960 |
DISCONTINUED Price: Call Us |
| 46 |
532429213 |
SHIELD.VAPOR(SKSN4606) Price: $44.99 |
| 47 |
532429316 |
OIL SEAL KIT NON-GENERATOR Price: $37.99 |
| 48 |
532429284 |
WIRE.HARNESS(SKSN4406) Price: $27.99 |
| 49 |
532429317 |
CRANKSHAFT.KEYED Price: $399.99 |
| 50 |
532435579 |
TOP.SHIELD.LCT. This part replaces 532429286. Price: $7.99 |
| 51 |
532429318 |
SKIRT FUEL TANK Price: $54.99 |
| 52 |
532429612 |
ROCKER ARM KIT Price: $19.99 |
| 53 |
532429606 |
PUSH ROD TAPPET KIT Price: $84.99 |
| 54 |
532429607 |
CYLINDER ASSY Price: $299.99 |
| 55 |
532429608 |
COUNTER WEIGHT KIT Price: $109.99 |
| 56 |
532429609 |
KIT.ENGINE GASKET.LCT.414CC Price: $37.99 |
| 57 |
532432146 |
FUEL HOSE KIT Price: $9.99 |
| 58 |
532432687 |
EXTENDED OIL DRAIN TUBE Price: $34.99 |
| 61 |
532432752 |
FUEL KNOB-SNOW Price: $7.99 |
| 62 |
532429242 |
NONREMVABLE.OIL.PLUG(SK4143715 Price: $8.99 |
| 63 |
532437466 |
CE COMPLIANT MUFFLER SHEILD Price: $39.99 |
