| Ref | Part Number | Description |
|---|
| 1 |
106-1094 |
KIT - RING & PINION This part replaces 100-2555. Price: $1,064.67 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO Price: $180.99 |
| 2 |
532140551 |
SEAT PIVOT BRKT Price: $3.99 |
| 2 |
99-7570 |
BEARING-ROLLER, TAPER Price: $61.91 |
| 3 |
871110616 |
Bolt Fin Hex 3/8-16 unc x 1 Price: $2.99 |
| 3 |
95-7534 |
CASE-BEARING Price: $176.21 |
| 4 |
106-1065 |
O-RING This part replaces 99-7571. Price: $9.02 |
| 4 |
819131610 |
WASHER PM Price: $3.99 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
99-7572 |
COLLAR-SEAL, OIL Price: $21.01 |
| 6 |
106-1066 |
O-RING This part replaces 99-7573. Price: $5.71 |
| 6 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 7 |
539110300 |
SRPING.SEAT This part replaces 532124181. Price: $2.99 |
| 7 |
99-7574 |
SEAL-OIL Price: $4.42 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 8 |
99-7559 |
WASHER-LOCK Price: $9.82 |
| 9 |
819131612 |
Washer 13/32 x 1 x 12 Ga. This part replaces 819131614. Price: $3.99 |
| 9 |
99-7560 |
NUT-LOCK Price: $27.76 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $14.99 |
| 10 |
99-7550 |
SHIM 0.1 Price: $4.34 |
| 10 |
99-7551 |
SHIM 0.2 Price: $4.55 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $4.99 |
| 11 |
95-7533 |
CASE-GEAR Price: $289.33 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT Price: $4.99 |
| 12 |
99-7575 |
BOLT Price: $4.00 |
| 13 |
532121248 |
BUSHING Price: $3.99 |
| 13 |
98-7735 |
STUD This part replaces 100-2556. Price: $1.36 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $3.99 |
| 14 |
99-7527 |
WASHER-SPRING Price: $1.02 |
| 15 |
532121249 |
SPACER SPLIT Price: $3.99 |
| 15 |
99-7526 |
NUT Price: $1.29 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 16 |
95-7541 |
PLATE-COVER Price: $89.04 |
| 17 |
106-1140 |
GASKET This part replaces 95-7540. Price: $17.66 |
| 17 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 532123976. Price: $2.69 |
| 21 |
532171852 |
BOLT.SHOULDER.5/16-18 Price: $3.99 |
| 22 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.69 |
| 24 |
819171912 |
WASHER Price: $3.99 |
