| Ref | Part Number | Description |
|---|
| 1 |
931-0220 |
Steering Wheel Cap This part replaces 731-0220. Price: $7.93 |
| 2 |
912-0158 |
Hex Cent. L.-Nut 5/16-18 Thd. This part replaces 712-0158. Price: $2.83 |
| 3 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 4 |
731-0356 |
STEERING WHEEL Not Available Price: |
| 5 |
750-0362 |
TUBE-STEER Not Available Price: |
| 6 |
736-0296 |
WASHER Not Available Price: |
| 7 |
736-0174 |
Wave Wash. .660 I.D. x .88 O.D. Price: $5.94 |
| 8 |
741-0138 |
BALL BEARING Not Available Price: |
| 9 |
13515-0637 |
STEERING COLUMN ASSEMBLY Not Available This part replaces 13515. Price: |
| 10 |
13586 |
DASH PANEL BASE PLATE ASS'Y Not Available Price: |
| 11 |
710-0623 |
Hex Self-Tap Scr. 3/8-16 x .75" Lg. Price: $3.93 |
| 12 |
710-0344 |
Hex Scr. 3/8-16 x 1.50" Lg. Price: $5.16 |
| 13 |
710-0514 |
Hex Bolt 3/8-16 x 1" Lg. This part replaces 710-0253. Price: $3.78 |
| 14 |
710-0502A |
Hx Wash Hd. Scr. 3/8-16 x 1.25" This part replaces 710-0502. Price: $5.71 |
| 15 |
13547 |
SHIELD-DUS Not Available Price: |
| 16 |
13032 |
BRACKET-PI Not Available Price: |
| 17 |
736-0169 |
L-Wash. 3/8" Scr. Price: $3.33 |
| 18 |
712-0798 |
Hex Nut 3/8-16 Thd. Price: $3.86 |
| 19 |
13008 |
Pivot Bar Ass'y. Price: Call Us |
| 20 |
936-0219 |
Bell-Wash. .400" I.D. x 1.13" O.D. This part replaces 736-0219. Price: $3.86 |
| 21 |
712-0375 |
Hex Cent. L-Nut 3/8-16 Thd. Price: $4.02 |
| 22 |
923-0179 |
Drag Link End This part replaces 723-0179. Price: $36.97 |
| 23 |
13001 |
AXLE ASSEMBLY- Not Available Price: |
| 24 |
747-0294 |
DRAG LINK Not Available Price: |
| 25 |
712-3029 |
NUT This part replaces 712-0922. Price: $6.01 |
| 26 |
736-0921 |
L-Wash. 1/2" Scr. Price: $3.90 |
| 27 |
747-0279 |
TIE ROD Not Available Price: |
| 28 |
13002 |
AXLE ASSEMBLY- Not Available Price: |
| 29 |
731-0556 |
Dust Cover Price: $4.22 |
| 30 |
714-0142 |
COTTER PIN-3/16 DIA x 1.50 Not Available Price: |
| 31 |
936-0259 |
FLAT WASHER Not Available This part replaces 736-0259. Price: |
| 32 |
734-1221 |
WHEEL ASSEMBLY 18X6.50 Not Available Price: |
| 33 |
931-0374 |
Bearing This part replaces 731-0374. Price: $6.84 |
| 34 |
936-0259 |
FLAT WASHER Not Available This part replaces 736-0259. Price: |
| 35 |
737-0146 |
Grease Fitting Price: $4.46 |
| 36 |
712-0798 |
Hex Nut 3/8-16 Thd. Price: $3.86 |
| 37 |
736-0169 |
L-Wash. 3/8" Scr. Price: $3.33 |
| 38 |
931-0349 |
Dust Cover This part replaces 731-0349. Price: $9.54 |
| 39 |
N/A |
See Ref. No. 16 |
| 40 |
710-0859 |
Screws 3/8-16X2.5 This part replaces 710-0937. Price: $5.99 |
| 41 |
941-0490 |
Flange Brg. w/Flats .75" I.D. This part replaces 741-0199. Price: $11.60 |
| 42 |
750-0333 |
SPACER Not Available Price: |
| 43 |
13132 |
ARM-STEERI Not Available Price: |
| 44 |
948-0238 |
BEVEL GEAR Not Available This part replaces 748-0238. Price: |
| 45 |
938-0342 |
STEERING SHAFT GEAR Not Available This part replaces 738-0342. Price: |
| 46 |
710-0344 |
Hex Scr. 3/8-16 x 1.50" Lg. Price: $5.16 |
| 47 |
736-0169 |
L-Wash. 3/8" Scr. Price: $3.33 |
| 48 |
736-0133 |
Fl-Wash. .406 I.D. x 1.25" O.D. Price: $4.67 |
| 49 |
736-0169 |
L-Wash. 3/8" Scr.* Price: $3.33 |
| 50 |
710-0216 |
Hex Scr. 3/8-16 x .75" Lg. Price: $3.93 |
| 51 |
710-0670 |
Nylon Hex Scr. 3/8-16 x 1.25" Lg. Price: $6.01 |
| 52 |
738-0408 |
STEERING SHAFT Not Available Price: |
| 53 |
912-3008 |
Jam Nut, 3/8-16 This part replaces 712-0342. Price: $4.08 |
| 54 |
936-0219 |
Bell-Wash. .400" I.D. x 1.13" O.D. This part replaces 736-0219. Price: $3.86 |
| 55 |
712-0239 |
Hex Ins. L-Nut 1/2-20 Thd. Price: $5.01 |
| 56 |
948-0227A |
Hex Flange Bearing Bronze .625" I.D. This part replaces 748-0227. Price: $7.61 |
| 57 |
948-0237 |
Pinion Gear This part replaces 748-0237. Price: $19.21 |
| 58 |
736-0264 |
Fl-Wash. 3/8" Dia. Price: $5.99 |
| 59 |
712-0237 |
Hex Cent. L-Nut 5/16-24 Thd. Price: $4.37 |
| 60 |
13539 |
SPACER Not Available Price: |
| 61 |
710-1039 |
Hex Bolt 3/8-24 x 1" Lg. This part replaces 710-0152. Price: $4.02 |
