| Ref | Part Number | Description |
|---|
| 1 |
117-2377 |
CABLE-BATTERY, NEGATIVE Price: $226.78 |
| 1 |
532186094 |
STEERING WHEEL.PREM.2.BLK This part replaces 532193651. Price: $169.99 |
| 2 |
121-6589 |
CABLE-BATTERY, POSITIVE Price: $199.46 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532184706. Price: $119.99 |
| 3 |
106-5190 |
BATTERY Price: $170.85 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
115-1794 |
SCREW-HHF Price: $1.73 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
3339-175 |
STRAPPING-WEB Price: $18.99 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
115-9100 |
BOX-STORAGE, BATTERY Price: $363.54 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
115-9101 |
BOX-STORAGE Price: $261.34 |
| 8 |
115-4387-0P |
SUPPORT-BOX, STORAGE This part replaces 115-4387-03. Price: $71.91 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
112-3306 |
NUT Price: $0.82 |
| 10 |
114-5502 |
CLIP-FUSE Price: $10.72 |
| 11 |
117-4783 |
SEAL-FOAM Price: $2.82 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
114-3321 |
CONTROLLER-TEC Price: $1,515.96 |
| 13 |
3234-6 |
SCREW-HHF Price: $3.19 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
99-7430 |
RELAY-MINI Price: $22.99 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 15 |
99-7435 |
RELAY Price: $32.43 |
| 16 |
42862 |
BLOCK-TERMINAL, GROUND Price: $19.58 |
| 17 |
110-8822 |
BLOCK-JUNCTION Price: $43.07 |
| 17 |
532190753 |
SHAFT STEERING SPLINE Price: $37.99 |
| 18 |
93-0231 |
SCREW-PPH Price: $0.61 |
| 19 |
32144-87 |
SCREW-HWHTF Price: $0.49 |
| 20 |
3296-54 |
NUT-LOCK Price: $3.59 |
| 21 |
112-3169 |
SCREW-HHF, SERRATED Price: $0.27 |
| 22 |
115-4356-03 |
MOUNT-FUSE BLOCK Price: $34.88 |
| 23 |
117-2360-03 |
BRACKET-MOUNT, CONTROLLER Price: $41.22 |
| 24 |
3217-6 |
NUT-HEX Price: $1.19 |
| 25 |
322-19 |
SCREW-HH Price: $5.99 |
| 26 |
321-8 |
SCREW-HH Price: $0.34 |
| 27 |
104-7201 |
NUT-HF Price: $0.69 |
| 28 |
125-4605 |
DECAL-FUSE Price: $9.79 |
| 29 |
125-4606 |
DECAL-SERVICE Price: $50.75 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
46-8091 |
SCREW-HWH Price: $3.59 |
| 31 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 32 |
42863 |
STRIP-JUMPER Price: $2.90 |
| 32 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN Price: $79.99 |
| 33 |
117-4768-03 |
PLATE-BOX, STORAGE Price: $8.81 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
117-4774-03 |
CLAMP Price: $69.62 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 39 |
596040001 |
Washers This part replaces 819113812. Price: $6.99 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 42 |
532145054 |
STEERING BOOT, GRAY This part replaces 532169634. Price: $11.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
532190752 |
SHAFT.EXTEN.STRG.SPLINE Price: $11.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK This part replaces 532195602. Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 97 |
874780564 |
BOLT Price: $4.99 |
