| Ref | Part Number | Description |
|---|
| 1 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 1 |
539103439 |
BAFFLE, 48" Price: $86.99 |
| 2 |
28-3680 |
TIRE Price: $118.18 |
| 2 |
539103440 |
DISCHARGE BAFFLE 48" Price: $119.99 |
| 3 |
217-60 |
RIM Price: $110.16 |
| 3 |
539101595 |
CLAMP Price: $24.99 |
| 4 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 4 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 5 |
10-6870-03 |
HUB-WHEEL This part replaces 10-6870. Price: $150.01 |
| 5 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 6 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 6 |
85-6540 |
STUD-DRIVE Price: $7.41 |
| 7 |
596580701 |
Nuts This part replaces 539990184. Price: $2.99 |
| 7 |
70-9840 |
SHOE-BRAKE Price: $60.36 |
| 8 |
321-5 |
SCREW-HH Price: $0.22 |
| 8 |
539101496 |
MULCH BLADE 16 1/4" Price: $12.95 |
| 9 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 9 |
539976940 |
CAPSCREW 5/16 X 4-1/2 HED HEAD Price: $1.13 |
| 10 |
325-11 |
SCREW-HH Price: $1.93 |
| 10 |
539103595 |
TEMPLATE Price: $8.46 |
| 11 |
147-3595 |
BRACKET-BRAKE This part replaces 84-2000. Price: $8.08 |
| 11 |
539103441 |
DEFLECTOR, CENTER Price: $24.99 |
| 12 |
32108-100 |
SCREW-FH Price: $3.02 |
| 13 |
49-5450 |
COVER PLATE *R Price: $79.55 |
| 14 |
57-614 |
Clamp-Tube, Side Price: Call Us |
| 15 |
340-14 |
FITTING-HYD, 45 DEG Price: $42.29 |
| 16 |
237-80 |
O-RING Price: $6.10 |
| 17 |
237-65 |
O-RING Price: $2.50 |
| 18 |
70-8600 |
HYDRAULIC HOSE ASSEMBLY Price: $203.81 |
| 19 |
70-7170 |
HYDRAULIC HOSE ASSEMBLY Price: $169.12 |
| 20 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 21 |
49-5430 |
ROD-CONTROL Price: $75.94 |
| 22 |
3220-2 |
NUT-JAM Price: $0.50 |
| 23 |
10-8220 |
TOOL BOX PAD Price: $24.12 |
| 24 |
49-5410 |
DISCONTINUED Price: Call Us |
| 25 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 27 |
93-2096 |
LEVER-BRAKE This part replaces 71-1510. Price: $89.45 |
| 29 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 30 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 31 |
62-2440 |
LIFT ARM ASM Price: $130.13 |
| 32 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 33 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 34 |
10-7820 |
PIVOT HINGE ASM Price: $504.57 |
| 35 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 36 |
57-7650 |
SPRING-TORSION Price: $11.81 |
| 37 |
62-2420-01 |
BAR ASM-LIFT, CTR ARM This part replaces 62-2420. Price: $70.22 |
| 38 |
136-8446 |
KIT, CENTER PULL FRAME This part replaces 83-0210. Price: $340.89 |
| 39 |
322-1 |
SCREW-HH Price: $0.22 |
| 40 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 41 |
131-4295 |
PIN-PIVOT This part replaces 10-6090. Price: $51.39 |
| 42 |
63-8750 |
PIN-PIVOT Price: $4.20 |
| 43 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 45 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 46 |
282-2 |
YOKE Price: $30.04 |
| 47 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 48 |
66-5292 |
DISCONTINUED Price: Call Us |
| 49 |
65-4640 |
KEY Price: $15.19 |
| 50 |
62-5070 |
DECAL-WARNING Price: $5.59 |
| 51 |
104-7708 |
BRAKE CAM & E-RING ASM This part replaces 70-9850. Price: $42.42 |
| 52 |
70-9870 |
PLATE-BACKING Price: $183.14 |
| 53 |
104-7708 |
BRAKE CAM & E-RING ASM This part replaces 70-9860. Price: $42.42 |
| 54 |
70-9880 |
SPRING-RETURN Price: $11.81 |
| 55 |
10-6821 |
BRAKE DRUM ASM This part replaces 10-6820. Price: $170.90 |
| 56 |
232-24 |
STEM-VALVE Price: $4.03 |
