| Ref | Part Number | Description |
|---|
| 1 |
32128-20 |
NUT-HF Price: $0.99 |
| 1 |
532166627 |
STEERING WHEEL Price: $64.99 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532184706. Price: $119.99 |
| 2 |
93-7703-03 |
PLATE-CLAMP, GUARD Price: $28.49 |
| 3 |
32153-3 |
NUT-HEX, SIDE DEFORM Price: $5.59 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 4 |
94-1756 |
CLAMP - MUFFLER Price: $12.55 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 5 |
93-4418-03 |
GUARD-MANIFOLD Price: $523.00 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
323-9 |
SCREW-HH Price: $1.29 |
| 10 |
32128-29 |
NUT-LOCK, FLANGE Price: $1.63 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
47-2830 |
SCREW Price: $0.34 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 12 |
93-4419-03 |
GUARD-MUFFLER, REAR Price: $298.94 |
| 13 |
322-6 |
SCREW-HH Price: $0.45 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
93-4417 |
U-BOLT Price: $30.13 |
| 15 |
3256-82 |
WASHER-FLAT Price: $0.47 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
93-4416-03 |
BRACKET-SUPPORT MUFFLER Price: $58.91 |
| 17 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 17 |
532177883 |
SHAFT ASM STRG Price: $104.99 |
| 18 |
93-0198-03 |
BRACKET-SUPPORT, MUFFLER Price: $70.77 |
| 19 |
46-6810 |
SCREW AND WASHER ASM Price: $3.49 |
| 22 |
93-4000-03 |
STRAP-SUPPORT, MUFFLER Price: $51.06 |
| 23 |
93-0199-03 |
STRAP-SUPPORT, MUFFLER Price: $61.23 |
| 24 |
33114-016 |
SCREW-HH Price: $0.27 |
| 25 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 26 |
2112-11 |
CLAMP-MUFFLER Price: $7.37 |
| 27 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
2412-103 |
CLAMP Price: $2.51 |
| 31 |
13-2650 |
BELT-V Price: $177.37 |
| 32 |
3-9155 |
KEY-SQUARE Price: $11.44 |
| 32 |
532180580 |
ROD TIE BALL J WSL Price: $109.99 |
| 33 |
13-3330 |
BUSHING Price: $47.20 |
| 34 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
321-6 |
SCREW-HH Price: $0.25 |
| 36 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 36 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 37 |
323-10 |
SCREW-HH Price: $0.89 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
4-1920 |
WASHER Price: $26.67 |
| 38 |
532172092 |
INSERT.CAP.STRG.WH (3 2) (L B) This part replaces 532166626. Price: $12.99 |
| 39 |
13-3320 |
SHEAVE Price: $893.43 |
| 39 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 40 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
107-1050 |
CLUTCH-CENTRIFUGAL This part replaces 106-9652. Price: $5,481.65 |
| 41 |
532159945 |
STEERING WHEEL ADAPTOR Price: $6.99 |
| 42 |
324-31 |
SCREW-HH Price: $6.65 |
| 43 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 46 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 47 |
3255-16 |
WASHER-LOCK/EXT Price: $0.61 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532169835. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 94 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $3.99 |
