| Ref | Part Number | Description |
|---|
| 1 |
532199298 |
DECK.WLDMNT.54".5GWB.GREY This part replaces 532195632. Price: $349.99 |
| 1 |
H192299 |
BLADE Price: $25.51 |
| 2 |
H292269 |
UP STOP BRACKET Price: $6.10 |
| 3 |
H292279 |
SCREW Price: $1.16 |
| 4 |
H292280 |
INSERT Price: $1.23 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $5.99 |
| 11 |
532187256 |
BLADE.BAGGING.54" Price: $17.99 |
| 12 |
532404851 |
ROD.ANTI.SWAY.48/54"K4 Price: $17.99 |
| 13 |
532187291 |
SHAFT ASM MANDREL Price: $17.99 |
| 14 |
532187281 |
HOUSING.MANDREL.4PT. Price: $22.99 |
| 15 |
532110485 |
BEARING Price: $7.99 |
| 16 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 18 |
872140505 |
BOLT Price: $2.99 |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $1.99 |
| 21 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $2.99 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $1.99 |
| 26 |
532110452 |
NUT PUSH M Price: $1.99 |
| 27 |
532187257 |
DEFLECTOR.BLACK.54" This part replaces 532188938. Price: $54.99 |
| 29 |
532131491 |
ROD.HINGE Price: $1.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $1.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $1.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $7.99 |
| 33 |
532400234 |
NUT.FLANGE.LOCK.TOP Price: $3.99 |
| 34 |
873680600 |
LOCKNUT Price: $1.99 |
| 39 |
532196104 |
PULLEY.IDLER.MWR.STATIONARY.LH This part replaces 532197380. Price: $22.99 |
| 43 |
532196065 |
ARM.IDLER Price: $11.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.99 |
| 47 |
587686701 |
BELT.DECK.DRIVE.BELT.54 This part replaces 532196103. Price: $44.99 |
| 49 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 50 |
872110616 |
BOLT Price: $3.99 |
| 52 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $14.99 |
| 58 |
532187342 |
BAFFLE.RIGHT.54" Price: $12.99 |
| 59 |
532187344 |
BAFFLE.LEFT.54" Price: $14.99 |
| 60 |
532187607 |
BAFFLE CENTER 54" MOWER Price: $17.99 |
| 97 |
532178515 |
WASHER Price: $2.99 |
| 98 |
532196105 |
SPRING, DECK DRIVE Price: $4.99 |
| 113 |
872110508 |
BOLT CRT Price: $2.99 |
| 114 |
532187556 |
ROD TENSION RELIEF Price: $12.99 |
| 116 |
532193406 |
BOLT.SHOULDER.3/8-16X3-5/8. Price: $1.99 |
| 117 |
532174873 |
WHEEL. GUAGE RALLY Price: $7.99 |
| 120 |
819132012 |
WASHER Price: $2.99 |
| 122 |
532187557 |
BUSHING.RELIEF.TENSION Price: $2.99 |
| 184 |
583612701 |
NUT HEX,LOCK,FLAN This part replaces 873900500. Price: $3.99 |
| 185 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 187 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 189 |
532195185 |
ARM.SUSPENSION.MOWER Price: $11.99 |
| 190 |
532196539 |
BOLT.SHOULDER Price: $4.99 |
| 192 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $5.99 |
| 194 |
874490736 |
BOLT.HEX.WASHER.HEAD.7/16-24X Price: $8.99 |
| 196 |
872140620 |
BOLT Price: $3.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $5.99 |
| 532187255 |
54" |
MULCH BLADE Price: $14.99 532187255 |
| 532416405 |
COUPLING.QUICK |
CONNECT Price: $5.99 532416405 |
