| Ref | Part Number | Description |
|---|
| 9 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 11 |
207005554 |
Hex Screw M10 X 1.5 X 55 Price: $7.69 |
| 12 |
207006544 |
Hex. Screw M10 X 1.5 X 65 Price: $2.99 |
| 13 |
207663056 |
Hex. Flange Screw M6 X 1.0 X 30 Price: $4.49 |
| 14 |
250000703 |
Hex. Screw M10 X 130 This part replaces 230003054. Price: $10.99 |
| 15 |
233201414 |
Hex. Flange Elastic Nut M10 Price: $1.59 |
| 16 |
233261466 |
Hex. Flange Elastic Nut M6 Price: $2.09 |
| 17 |
233281414 |
Hex. Flange Elastic Nut M8 Price: $1.49 |
| 18 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 19 |
250001022 |
Screw Hex. M10 X 50 This part replaces 250000289. Price: $1.69 |
| 20 |
250001023 |
Screw Hex. M10 X 60 This part replaces 250000290. Price: $2.19 |
| 21 |
250001024 |
Screw Hex. M10 X 70 This part replaces 250000291. Price: $2.19 |
| 22 |
250100165 |
Hex. Flange Elastic Nut M10 Price: $0.87 |
| 23 |
232521464 |
Hex Elastic Nut M12 X 1.25 Price: $2.19 |
| 24 |
293370035 |
Circlip Price: $2.69 |
| 25 |
293370070 |
Circlip Price: $9.19 |
| 46 |
503187500 |
Spring Guide Price: $10.99 |
| 47 |
503189564 |
Washer Price: $0.76 |
| 50 |
503192491 |
Washer Price: $4.69 |
| 51 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 52 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 53 |
505073625 |
Adjustment Cam This part replaces 505070150. Price: $13.49 |
| 54 |
505070917 |
Yellow Handle Price: $43.99 |
| 58 |
505071781 |
Ski Bushing Price: $16.18 |
| 59 |
505071812 |
Retainer 17mm long Price: $6.09 |
| 60 |
505073265 |
Deep Black, Spring Price: $69.99 |
| 61 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 62 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 63 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 64 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 66 |
505072664 |
Black, RH Lower Arm Price: $204.99 |
| 66 |
505072665 |
Black, LH Lower Arm Price: $204.99 |
| 77 |
505072064 |
Bushing Price: $2.32 |
| 79 |
506133300 |
Spacer Price: $23.99 |
| 80 |
505072133 |
Retainer 23mm Long Price: $6.89 |
| 82 |
505072143 |
Sleeve Price: $9.00 |
| 84 |
505072854 |
Deep Black, LH Pilot 5.7 Ski This part replaces 505072942. Price: $184.99 |
| 84 |
505072855 |
Deep Black, RH Pilot 5.7 Ski This part replaces 505072943. Price: $169.99 |
| 85 |
505072204 |
Sway Bar Double Joint Link Price: $21.99 |
| 87 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 88 |
505072208 |
Bushing Price: $3.28 |
| 90 |
505072250 |
Bushing Price: $3.28 |
| 91 |
505073636 |
Ball Joint This part replaces 505072682. Price: $51.99 |
| 99 |
505072392 |
Washer Price: $4.89 |
| 100 |
505072209 |
Sleeve This part replaces 505072393. Price: $17.84 |
| 101 |
505072394 |
Stabilisator Lever Price: $18.99 |
| 103 |
860201044 |
Carbide Runner Kit (Square Runner) Price: $129.99 |
| 105 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 107 |
505072448 |
O-Ring Price: $2.39 |
| 110 |
505072594 |
Ski Stopper Price: $18.49 |
| 111 |
505072602 |
Stabilisator Price: $71.99 |
| 113 |
505072634 |
Wear Plate Price: $6.39 |
| 114 |
505072690 |
Leg Bushing Price: $12.49 |
| 115 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 117 |
505072913 |
Upper Ball Joint Price: $72.99 |
| 120 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 121 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 122 |
505073007 |
Clear, LH Ski Leg Price: $254.99 |
| 127 |
505073462 |
Black LH Upper Arm, 42" Price: $154.99 |
| 127 |
505073463 |
Black RH Upper Arm, 42" Price: $154.99 |
| 133 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 135 |
516005535 |
Shock Decal "Mc" Price: $13.49 |
| 136 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 137 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 141 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 142 |
706200881 |
Spring Stopper Price: $13.49 |
| 143 |
503192496 |
Washer Price: $0.79 |
| 145 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 148 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 149 |
505073180 |
Front Shock Price: $164.49 |
| 153 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 153a |
XXX |
Not Available As Spare Parts Price: Call Us |
| 153b |
XXX |
Not Available As Spare Parts Price: Call Us |
| 153c |
XXX |
Not Available As Spare Parts Price: Call Us |
| 153d |
XXX |
Not Available As Spare Parts Price: Call Us |
| 153e |
XXX |
Not Available As Spare Parts Price: Call Us |
| 156 |
XXX |
Not Available As Spare Parts Price: Call Us |
| 156a |
XXX |
Not Available As Spare Parts Price: Call Us |
| 156b |
XXX |
Not Available As Spare Parts Price: Call Us |
| 156c |
XXX |
Not Available As Spare Parts Price: Call Us |
| 156d |
XXX |
Not Available As Spare Parts Price: Call Us |
| 156e |
XXX |
Not Available As Spare Parts Price: Call Us |
