| Ref | Part Number | Description |
|---|
| 13236 |
13236-0065 |
LEVER-COMP Price: $93.07 |
| 14091 |
14091-0487 |
COVER Price: $14.36 |
| 16014 |
16014-0002 |
SCREW-PILOT AIR Price: $25.16 |
| 16021 |
16021-0009 |
SCREW-THROTTLE STOP Price: $123.88 |
| 16073 |
16073-3707 |
INSULATOR Price: $6.18 |
| 16163 |
16163-0043 |
THROTTLE-ASSY Price: $2,419.61 |
| 21176 |
21176-0002 |
SENSOR,TPS,MAIN Price: $217.59 |
| 21176A |
21176-0003 |
SENSOR,MAIN Price: $217.59 |
| 26030 |
26030-1672 |
HARNESS Price: $129.64 |
| 31064 |
31064-0019 |
PIPE-COMP,FUEL Price: $69.08 |
| 31064A |
31064-0020 |
PIPE-COMP,FUEL Price: $41.11 |
| 32144 |
32144-0003 |
PIPE-ASSY,FUEL Price: $41.11 |
| 49033 |
49033-0003 |
NOZZLE-INJECTION Price: $134.55 |
| 49056 |
49056-0007 |
PIPE-INJECTION Price: $112.23 |
| 49056A |
49056-0008 |
PIPE-INJECTION Price: $112.23 |
| 59071 |
59071-3752 |
JOINT,3WAY,T Price: $10.19 |
| 92001 |
92001-1998 |
BOLT,THROTTLE ADJUST Price: $16.94 |
| 92033 |
92033-0004 |
RING-SNAP,FAST IDLE Price: $2.78 |
| 92055 |
92055-1622 |
RING-O,INJECTION NOZZLE Price: $1.95 |
| 92055A |
92055-1671 |
RING-O Price: $3.73 |
| 92068 |
92068-006 |
PLUG,12X25 Price: $4.26 |
| 92072 |
92072-0012 |
BAND,SUB-HARNESS Price: $5.00 |
| 92081 |
92081-1620 |
SPRING Price: $4.96 |
| 92144 |
92144-1451 |
SPRING Price: $9.58 |
| 92151 |
92153-1598 |
BOLT,FLANGED,6X22 This part replaces 92151-1236. Price: $2.15 |
| 92172 |
92172-0064 |
SCREW,PIPE INJECTION Price: $2.80 |
| 92172A |
92172-0080 |
SCREW Price: $5.00 |
| 92172B |
92172-0169 |
SCREW Price: $5.00 |
| 92191 |
92191-0025 |
TUBE Price: $2.43 |
| 92191A |
92191-0150 |
TUBE,3X7X45 Price: $8.05 |
| 92191B |
92191-0151 |
TUBE,3X7X110 Price: $10.20 |
| 92191C |
92191-0152 |
TUBE,3X7X160.5 Price: $15.20 |
| 92200 |
92200-0033 |
WASHER,FAST IDLE Price: $2.80 |
