| Ref | Part Number | Description |
|---|
| 1 |
13064-5005 |
LEVER-ASSY-KICK PEDAL Price: $177.67 |
| 2 |
13061-5001 |
BOSS,KICK PEDAL Price: $61.75 |
| 3 |
290Q0808 |
SCREW,8X8 Price: $4.78 |
| 4 |
482K0100 |
CIR CLIP Price: $0.70 |
| 5 |
600A0800 |
BALL-STEEL,1/4 Price: $0.62 |
| 6 |
670B2012 |
O RING,12MM Price: $3.23 |
| 7 |
92001-1042 |
BOLT,HEX HEAD,8X28 Price: $6.69 |
| 8 |
92022-1019 |
WASHER,PLAIN Price: $5.23 |
| 9 |
92081-020 |
SPRING,KICK PEDAL Price: $4.26 |
| 10 |
13066-1005 |
SHAFT,KICKSTARTER Price: $84.68 |
| 11 |
13070-008 |
GUIDE,KICKSPRING Price: $11.02 |
| 12 |
13078-1052 |
RATCHET,KL250-D2 Price: $66.54 |
| 13 |
480J1600 |
CIRCLIP-TYPE-C,16MM Price: $4.31 |
| 14 |
59051-1008 |
GEAR,KICKSTARTER Price: $141.91 |
| 15 |
92022-315 |
WASHER,16.8X22X0.5 Price: $6.22 |
| 16 |
92081-122 |
SPRING,RATCHET Price: $8.79 |
| 17 |
92082-005 |
SPRING,KICKSTARTER Price: $21.98 |
| 18 |
92022-268 |
WASHER,PLAIN Price: $8.95 |
| 19 |
92022-269 |
WASHER,PLAIN Price: $1.25 |
| 20 |
92043-102 |
PIN Price: $3.27 |
| 21 |
480J1500 |
CIRCLIP-TYPE-C,15MM Price: $2.31 |
| 22 |
59051-1009 |
IDLE GEAR,KICKSTARTER Price: $100.60 |
| 23 |
92022-1045 |
WASHER,PLAIN Price: $5.59 |
| 24 |
112BA0618 |
BOLT-UPSET This part replaces 112G0618. Price: $1.03 |
| 25 |
13206-1061 |
GUIDE-KICK This part replaces 13206-1059. Price: $11.80 |
