| Ref | Part Number | Description |
|---|
| 2 |
33032-042 |
SHAFT,SWING ARM PIVOT Price: $67.70 |
| 3 |
33034-020 |
SLEEVE,SWING ARM Price: $36.37 |
| 6 |
92019-017 |
NUT,12MM Price: $3.85 |
| 7 |
33040-067 |
ADJUSTER,CHAIN Price: $21.48 |
| 8 |
92001-132 |
BOLT,CHAIN ADJUSTER Price: $6.25 |
| 9 |
312G0800 |
NUT,8MM Price: $3.22 |
| 10 |
55020-017 |
GUARD,CHAIN,L.H Price: $35.51 |
| 11 |
55020-018 |
GUARD,CHAIN,R.H Price: $35.51 |
| 12 |
55020-019 |
GUARD,CHAIN Price: $30.15 |
| 13 |
110R0635 |
BOLT 6X35 Price: $5.96 |
| 14 |
112G0640 |
BOLT-UPSET,6X40 Price: $3.42 |
| 15 |
92019-019 |
NUT,6MM Price: $9.48 |
| 16 |
45014-104 |
SHOCK ABSBR RR Price: $198.11 |
| 17 |
112BA0614 |
BOLT-UPSET This part replaces 112G0614. Price: $2.10 |
| 18 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 19 |
92022-228 |
WASHER,7X24X1.6 Price: $3.92 |
| 20 |
92001-133 |
BOLT,HEX HEAD,12X35 Price: $4.11 |
| 21 |
43007-040 |
TORQUE LINK,RR BRAKE Price: $9.39 |
| 22 |
92043-105 |
PIN,TORQUE LINK Price: $12.41 |
| 23 |
92022-239 |
WASHER,10.5X20X1 Price: $3.92 |
| 24 |
550AA2020 |
PIN-COTTER,2.0X20 This part replaces 550D2020. Price: $1.04 |
| 25 |
92019-016 |
NUT,10MM Price: $4.79 |
| 26 |
113G1028 |
BOLT,10X28 Price: $9.34 |
