| Ref | Part Number | Description |
|---|
| 2 |
220E0435A |
SCREW-PAN HEAD,4X35 Price: $8.56 |
| 3 |
23026-023 |
LENS-TAIL LAMP Price: $131.51 |
| 4 |
92069-028 |
BULB,6V 17/5.3W Price: $9.63 |
| 5 |
23028-018 |
GASKET-TAIL LAMP LENS Price: $12.32 |
| 6 |
23027-030 |
CASE,TAIL LAMP Price: $142.14 |
| 8 |
92075-076 |
DAMPER RUBBER Price: $4.78 |
| 9 |
92027-129 |
COLLAR,6.8X10X8.5 Price: $5.00 |
| 10 |
92200-0283 |
WASHER,6.5X20X1.6 This part replaces 92022-125. Price: $1.40 |
| 11 |
112BA0622 |
BOLT-UPSET This part replaces 112B0622. Price: $3.74 |
| 12 |
92071-019 |
GROMMET HARNESS 10MM Price: $3.89 |
| 13 |
112BA0630 |
BOLT-UPSET This part replaces 112G0630. Price: $1.38 |
| 14 |
92200-0283 |
WASHER,6.5X20X1.6 This part replaces 92022-125. Price: $1.40 |
| 15 |
35039-005 |
DAMPER-TAIL LAMP SHCK Price: $10.53 |
| 16 |
312AA0600 |
NUT-HEX This part replaces 312B0600. Price: $0.73 |
| 17 |
28013-005 |
BRACKET-REFLECTOR Price: $20.33 |
| 18 |
28012-008 |
REFLECTOR-REFLEX,REAR Price: $13.07 |
| 19 |
461DA0500 |
WASHER-SPRING,5MM This part replaces 461F0500. Price: $0.71 |
| 20 |
322N0500 |
NUT-CAP,5MM Price: $4.06 |
| 21 |
23037-005 |
LAMP ASY-FR TURN SIG Price: $99.53 |
| 22 |
220E0420A |
SCREW-PAN HEAD,4X20 Price: $2.76 |
| 23 |
23058-002 |
WASHER,PLAIN,4MM Price: $2.49 |
| 24 |
23048-1001 |
LENS,TURN SIGNAL LAMP Price: $10.57 |
| 25 |
92069-056 |
BULB,6V 21CP Price: $6.41 |
| 26 |
23050-003 |
GASKET-SIG LAMP LENS Price: $5.80 |
| 27 |
112BA0630 |
BOLT-UPSET This part replaces 112G0630. Price: $1.38 |
| 28 |
411S0600 |
WASHER-PLAIN,6MM This part replaces 411D0600. Price: $2.06 |
| 29 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 30 |
311AA0600 |
NUT-HEX,6MM This part replaces 311B0600. Price: $0.96 |
| 31 |
23051-1004 |
BRACKET,FRNT TURN SIG Price: $38.07 |
| 32 |
23051-1013 |
BRACKET,SIGNAL LAMP Price: $22.30 |
| 33 |
410S0500 |
W-PLAIN-S,5MM This part replaces 410D0500. Price: $1.59 |
| 34 |
461DA0500 |
WASHER-SPRING,5MM This part replaces 461F0500. Price: $0.71 |
| 35 |
110R0516 |
BOLT,5X16 This part replaces 110N0516. Price: $3.75 |
| 36 |
23066-003 |
DAMPER RUBBER Price: $7.71 |
| 37 |
92009-1123 |
SCREW,3X5 This part replaces 220B0305A. Price: $0.59 |
| 38 |
26011-061 |
WIRE-TURN SIGNAL LEAD Price: $5.44 |
| 39 |
26009-004 |
COVER-WIRING HARNESS Price: $1.97 |
| 40 |
23040-033 |
LAMP-REAR TURN SIGNAL Price: $147.39 |
| 41 |
23051-044 |
BKT-RR SIGNAL LAMP Price: $31.36 |
| 42 |
92075-148 |
DAMPER RUBBER Price: $4.03 |
| 43 |
92027-168 |
COLLAR 12.7X17.3X30 Price: $4.57 |
| 44 |
92081-111 |
SPRING Price: $3.45 |
| 45 |
92022-235 |
WASHER CUP 12.5X35X4T Price: $5.51 |
| 46 |
92037-087 |
CLAMP-RR SIGNAL LAMP Price: $3.83 |
| 47 |
461DA1200 |
WASHER-SPRING,12MM This part replaces 461F1200. Price: $1.03 |
