| Ref | Part Number | Description |
|---|
| 2 |
13180-001 |
SHAFT COUTER Price: $43.98 |
| 3 |
49047-1005 |
ROD,SHIFT Price: $72.57 |
| 6 |
13144-038 |
ENGINE SPROCKET 15T Price: $130.36 |
| 7 |
480J2400 |
CIRCLIP-TYPE-C,24MM Price: $6.32 |
| 8 |
13128-035 |
SHAFT-OUTPUT Price: $158.90 |
| 9 |
600A1000 |
BALL-STEEL,5/16 Price: $0.73 |
| 10 |
13137-012 |
TOP GEAR OUTPUT SHAFT Price: $42.06 |
| 11 |
92033-014 |
CIRCLIP Price: $5.17 |
| 12 |
92024-030 |
WASHER-LOCK Price: $6.15 |
| 14 |
92022-146 |
WASHER THRUST Price: $8.21 |
| 16 |
13129-1708 |
GEAR-TRANSMISSION SPU Price: $92.35 |
| 17 |
13129-010 |
LOW GEAR OUTPUT SHAFT Price: $87.77 |
| 18 |
13073-004 |
IDLE GEAR Price: $74.27 |
| 19 |
13075-004 |
PINION KICKSTARTER Price: $52.38 |
| 20 |
13127-032 |
SHAFT,DRIVE Price: $115.91 |
| 22 |
92022-118 |
WASHER THRUST Price: $4.69 |
| 24 |
13129-1927 |
GEAR,INPUT TOP,24T Price: $34.88 |
| 25 |
600A0700 |
BALL STEEL 7/32' Price: $1.64 |
| 26 |
92022-115 |
WASHER THRUST Price: $4.39 |
| 27 |
220AA0616 |
SCREW-PAN-CROS,6X16 This part replaces 220B0616. Price: $3.04 |
| 28 |
220AA0614 |
SCREW-PAN-CROS,6X14 This part replaces 220B0614. Price: $1.48 |
| 30 |
13146-002 |
GASKET NEUTRAL SWITCH Price: $4.35 |
| 31 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 32 |
21007-1003 |
ROTOR,NEUTRAL INDICTR Price: $7.62 |
| 33 |
410AA0600 |
WASHER-PLAIN-SMALL This part replaces 410B0600. Price: $1.31 |
| 34 |
13239-005 |
DRUM ASSY-GEAR CHANGE Price: $183.14 |
| 35 |
13140-009 |
FORK SELECTOR 3RD Price: $66.96 |
| 36 |
13140-017 |
FORK SELECTOR 4TH-TOP Price: $156.47 |
| 37 |
13140-010 |
FORK SELECTOR LOW-2ND Price: $151.87 |
| 38 |
92043-005 |
PIN SELECT FORK GUIDE Price: $5.40 |
| 39 |
550AA3020 |
PIN-COTTER,3.0X20 This part replaces 550D3020. Price: $1.78 |
| 40 |
92042-014 |
PIN,DOWEL,4X15.8 Price: $0.43 |
| 41 |
13142-008 |
PLATE CHANGE DRUM PIN Price: $3.78 |
| 42 |
464H0600 |
WASHER LOCK 6MM Price: $0.68 |
