| Ref | Part Number | Description |
|---|
| 311 |
311BA0600 |
NUT-HEX,6MM Price: $2.23 |
| 311A |
311BB0600 |
NUT-HEX,6MM Price: $1.04 |
| 670 |
670B2012 |
O RING,12MM Price: $3.23 |
| 13165 |
13165-0003 |
PAWL,CHANGE SHAFT Price: $4.09 |
| 13172 |
13172-0009 |
SHAFT-ASSY-CHANGE This part replaces 13172-0005. Price: $74.13 |
| 13236 |
13236-0157 |
LEVER-COMP,POSITION Price: $10.03 |
| 13242 |
13242-0034 |
LEVER-ASSY-CHANGE Price: $39.81 |
| 13242A |
13242-0134 |
LEVER-ASSY-CHANGE,PEDAL This part replaces 13242-0035. Price: $65.32 |
| 39110 |
39110-0027 |
ROD-ASSY-TIE Price: $8.68 |
| 92002 |
92002-1237 |
BOLT,6X20 Price: $4.31 |
| 92004 |
92004-0032 |
STUD,6X12 Price: $1.79 |
| 92015 |
92015-1178 |
NUT,LEFT HANDED,6MM Price: $4.31 |
| 92022 |
92022-1827 |
WASHER,6X12.8X1.2 Price: $4.69 |
| 92026 |
92026-1217 |
SPACER Price: $5.52 |
| 92033 |
92033-1178 |
RING-SNAP,TYPE-E,10MM Price: $4.26 |
| 92081 |
92081-1829 |
SPRING,CHANGE LEVER Price: $8.79 |
| 92081A |
92081-1993 |
SPRING,POSITION LEVER Price: $6.51 |
| 92144 |
92144-1345 |
SPRING,CHANGE PEDAL RETURN Price: $17.44 |
| 92153 |
92153-1144 |
BOLT,8X15.5 Price: $1.63 |
