| Ref | Part Number | Description |
|---|
| 1 |
172G1075 |
STUD 10X75 Price: $14.53 |
| 2 |
220AA0675 |
SCREW-PAN HEAD,6X75 This part replaces 220B0675. Price: $5.00 |
| 3 |
14001-065 |
CRANKCASE SET Price: $397.54 |
| 4 |
221AA0616 |
SCREW-CSK-CROS,6X16 This part replaces 221B0616. Price: $0.59 |
| 5 |
92043-1037 |
PIN,DOWEL,10X14 Price: $0.74 |
| 6 |
14014-019 |
HOLDER-CRANK BEARING Price: $8.06 |
| 7 |
14003-056 |
CRANKCASE,R.H Price: $99.03 |
| 9 |
670B1505 |
O RING,5MM Price: $3.26 |
| 11 |
92062-004 |
NOZZLE OIL INJECTION Price: $10.69 |
| 12 |
14019-044 |
COVER-ROTARY DISC VLV Price: $46.53 |
| 13 |
220AA0620 |
SCREW-PAN-CROS,6X20 This part replaces 220B0620. Price: $5.82 |
| 15 |
16128-006 |
VALVE-CHECK Price: $13.78 |
| 16 |
653B354808 |
OIL SEAL TB35488 Price: $18.22 |
| 17 |
610A0512 |
PIN DOWEL 5X12 Price: $4.78 |
| 18 |
601B6205 |
BEARING BALL #6205 Price: $19.57 |
| 19 |
14014-020 |
HOLDER-MISSION BERNG Price: $1.73 |
| 20 |
220AA0614 |
SCREW-PAN-CROS,6X14 This part replaces 220B0614. Price: $1.48 |
| 21 |
92071-042 |
GROMMET,BREATHER Price: $4.26 |
| 22 |
92059-061 |
PIPE-BREATHER Price: $6.12 |
| 23 |
14069-1062 |
BREATHER This part replaces 14069-1001. Price: $24.64 |
| 24 |
112BA0620 |
BOLT-UPSET This part replaces 112G0620. Price: $2.28 |
| 25 |
11015-021 |
INLET PIPE Price: $23.69 |
| 26 |
11017-005 |
GASKET-INLET PIPE Price: $4.04 |
| 27 |
92045-016 |
BEARING-BALL Price: $50.30 |
| 28 |
220B0650 |
SCREW-PAN-CROS,6X50 Price: $0.98 |
| 29 |
601B6305 |
BEARING-BALL,#6305C3 Price: $25.78 |
| 30 |
92049-1482 |
SEAL-OIL This part replaces 92049-1250. Price: $18.74 |
| 31 |
92050-033 |
OIL SEAL TB3040 Price: $21.74 |
| 32 |
92049-004 |
OIL SEAL SB12205 Price: $9.58 |
| 33 |
14076-001 |
COVER-WIRING HARNESS Price: $3.43 |
| 34 |
220AA0630 |
SCREW-PAN-CROS,6X30 This part replaces 220B0630. Price: $3.67 |
| 35 |
92071-051 |
GROMMET Price: $0.90 |
