| Ref | Part Number | Description |
|---|
| 130 |
130BA0612 |
BOLT-FLANGED,6X12 Price: $1.72 |
| 311 |
311AB0500 |
NUT-HEX,5MM Price: $0.43 |
| 11047 |
11047-1470 |
BRACKET,REFLECTOR Price: $29.08 |
| 11054 |
11054-1904 |
BRACKET,SIDE STAND SWITCH Price: $11.28 |
| 11056 |
11056-0264 |
BRACKET,KEY CYLINDER Price: $7.71 |
| 11056A |
11056-1074 |
BRACKET Price: $8.21 |
| 11056B |
11056-1084 |
BRACKET Price: $13.49 |
| 21007 |
21007-5068 |
ROTOR,LOCK,TANK CAP Price: $88.32 |
| 27005 |
27005-0556 |
SWITCH-ASSY-IGNITION This part replaces 27005-0062. Price: $186.67 |
| 27010 |
27010-0112 |
SWITCH,SIDE STAND Price: $71.04 |
| 27010A |
27010-1486 |
SWITCH,REAR BRAKE Price: $35.01 |
| 27016 |
27016-1115 |
LOCK-ASSY,SEAT STRIKER Price: $28.59 |
| 27016A |
27016-5368 |
LOCK-ASSY,SEAT Price: $90.40 |
| 27045 |
27045-5470 |
SWITCH-ASSY This part replaces 27045-5434. Price: $429.04 |
| 28012 |
28012-0001 |
REFLECTOR-REFLEX,FR,SIDE Price: $24.14 |
| 28012A |
28012-0002 |
REFLECTOR-REFLEX Price: $24.14 |
| 28012B |
28012-1077 |
REFLECTOR-REFLEX Price: $23.25 |
| 56054 |
56054-0642 |
MARK,IGNITION SWITCH Price: $11.63 |
| 92002 |
112BA0612 |
BOLT-UPSET This part replaces 92002-1132. Price: $1.49 |
| 92015 |
92015-1367 |
NUT,FLANGED,6MM Price: $3.69 |
| 92075 |
92075-1564 |
DAMPER Price: $5.48 |
| 92145 |
92145-0761 |
SPRING,BRAKE LAMP SWITCH Price: $3.96 |
| 92151 |
92154-1858 |
BOLT,TORX,6X22 This part replaces 92151-1946. Price: $3.94 |
| 92152 |
92152-1074 |
COLLAR Price: $6.22 |
| 92154 |
92154-1898 |
BOLT,SOCKET,6X22 This part replaces 92154-0031. Price: $2.12 |
| 92161 |
92161-0117 |
DAMPER Price: $2.90 |
| 92161A |
92161-0118 |
DAMPER Price: $2.90 |
| 92200 |
92200-0212 |
WASHER,6X20X1.6 Price: $3.35 |
| 92210 |
92210-0003 |
NUT,CAP,6MM Price: $0.64 |
