| Ref | Part Number | Description |
|---|
| 1 |
56001-005 |
REAR VIEW MIRROR Price: $12.32 |
| 2 |
46109-012 |
LEVER ASSY,STARTER Price: $24.86 |
| 3 |
46003-018 |
HANDLEBAR Price: $31.23 |
| 4 |
46019-005 |
GRIP ASSY THROTTLE Price: $79.71 |
| 5 |
46017-1071 |
GRIP-ASSY,RH Price: $101.50 |
| 6 |
46022-012 |
CASE R.H SWITCH LOWER Price: $27.75 |
| 7 |
46058-004 |
LEVER FRONT BRAKE Price: $24.84 |
| 9 |
46032-010 |
WIRING HARNESS R.H SW Price: $5.86 |
| 10 |
46037-009 |
HOLDER R.H SWITCH Price: $3.96 |
| 11 |
46043-002 |
KNOB ASSY R.H SWITCH Price: $4.20 |
| 12 |
46045-004 |
SLIDE BLOCK AY R.H SW Price: $6.25 |
| 13 |
46085-012 |
HOLDER WIRING HARNESS Price: $1.91 |
| 16 |
464EA0500 |
WASHER-TOOTHED This part replaces 464H0500. Price: $1.01 |
| 20 |
92210-1131 |
NUT,CABLE ADJUST LOCK This part replaces 46056-001. Price: $5.55 |
| 22 |
46075-007 |
RUBBER L.H GRIP Price: $38.70 |
| 23 |
46077-008 |
CASE L.H SWITCH LOWER Price: $29.95 |
| 24 |
46092-015 |
LEVER-CLUTCH Price: $20.99 |
| 25 |
46085-008 |
HOLDER L.H SWITCH Price: $4.87 |
| 26 |
46086-007 |
CASE L.H SWITCH UPPER Price: $17.82 |
| 27 |
46088-001 |
KNOB ASSY L.H SWITCH Price: $8.74 |
| 28 |
27010-1009 |
SWITCH ASSY,HORN BUTN This part replaces 46078-003. Price: $9.20 |
| 29 |
46089-002 |
SLIDE BLOCK AY L.H SW Price: $11.26 |
| 30 |
46082-011 |
WIRING HARNESS L.H SW Price: $19.35 |
| 31 |
46061-009 |
RUBBER R.H GRIP Price: $7.73 |
| 32 |
46004-014 |
HANDLEBAR Price: $105.93 |
| 33 |
92001-1405 |
BOLT 8X38 Price: $16.50 |
| 34 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 35 |
46012-1252 |
HOLDER-HANDLE,UPP This part replaces 46012-004. Price: $13.44 |
| 36 |
46012-007 |
HOLDER HANDLEBAR LOW Price: $16.15 |
| 37 |
46016-003 |
CAP HANDLEBAR HOLDER Price: $6.74 |
| 38 |
92075-039 |
DAMPER,HANDLE HOLDER Price: $4.69 |
| 39 |
46016-003 |
CAP HANDLEBAR HOLDER Price: $6.74 |
| 40 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 41 |
314AA1000 |
NUT-HEX-FINE This part replaces 314B1000. Price: $0.68 |
| 42 |
550AA2520 |
PIN-COTTER,2.5X20 This part replaces 550D2520. Price: $1.36 |
| 43 |
116B0840 |
BOLT HEX HEAD 8X40 Price: $0.54 |
| 44 |
410AA0800 |
WASHER-PLAIN-SMALL,8MM This part replaces 410B0800. Price: $0.96 |
| 45 |
317AA0800 |
NUT-HEX-SMALL,8MM This part replaces 311B0800. Price: $0.68 |
| 46 |
46005-006 |
HANDLEBAR,LOW Price: $35.30 |
