| Ref | Part Number | Description |
|---|
| 1 |
92020-003 |
NUT,CAP,10MM Price: $6.52 |
| 2 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 4 |
45014-1017 |
SHOCK ABSBR RR Price: $237.73 |
| 4 |
45014-113 |
SHOCK ABSBR RR Price: $259.62 |
| 5 |
45017-010 |
BUSH A-SHCK ABS RUBER Price: $10.17 |
| 6 |
92075-1020 |
DAMPER,SHOCKABSORBER Price: $4.92 |
| 7 |
45016-003 |
BUSH SHCK ABS PVT SFT Price: $15.92 |
| 9 |
33032-034 |
SHAFT-SWING ARM PIVOT Price: $38.31 |
| 11 |
33035-005 |
CAP-SWINGING ARM Price: $8.37 |
| 13 |
33033-009 |
BUSHING-SWING ARM Price: $99.19 |
| 14 |
670B2016 |
O RING,16MM Price: $1.36 |
| 15 |
33034-016 |
SLEEVE-SWINGING ARM Price: $21.33 |
| 16 |
33036-007 |
COLLAR,SWING ARM,LONG Price: $9.82 |
| 17 |
33001-063 |
ARM,SWINGING Price: $167.95 |
| 18 |
92210-1373 |
NUT,LOCK,12MM This part replaces 92019-009. Price: $7.29 |
| 20 |
55020-016 |
GUARD,CHAIN Price: $21.87 |
| 21 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 22 |
314AA1000 |
NUT-HEX-FINE This part replaces 314B1000. Price: $0.68 |
| 23 |
115BA0816 |
BOLT-SMALL-UPSET This part replaces 115G0816. Price: $0.70 |
| 24 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 25 |
92001-1252 |
BOLT,HEX HEAD 10X35 Price: $7.65 |
| 26 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 27 |
33040-057 |
ADJUSTER,CHAIN Price: $24.88 |
| 28 |
33041-002 |
PLATE-CHAIN ADJUSTER Price: $17.31 |
| 29 |
317AA0800 |
NUT-HEX-SMALL,8MM This part replaces 311B0800. Price: $0.68 |
| 30 |
92003-143 |
BOLT,HEX HEAD,AX24 Price: $3.89 |
| 31 |
43007-039 |
TORQUE LINK,REAR BRK Price: $14.78 |
| 32 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 33 |
320B0800 |
NUT,8MM Price: $2.42 |
| 34 |
550AA2020 |
PIN-COTTER,2.0X20 This part replaces 550D2020. Price: $1.04 |
| 35 |
92003-144 |
BOLT,RR TORQUE LINK Price: $6.84 |
| 37 |
92076-024 |
RUBBER,REAR FOOTREST Price: $24.87 |
| 38 |
92022-199 |
WASHER-PLAIN (OPT) Price: $11.60 |
| 39 |
92043-1464 |
PIN,6X28 Price: $8.10 |
| 40 |
550AA2012 |
PIN,COTTER,2.0X12 This part replaces 550D2012. Price: $1.11 |
| 41 |
34029-013 |
BRACKET,REAR FOOTREST Price: $23.54 |
| 42 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
