| Ref | Part Number | Description |
|---|
| 220 |
220AB0416 |
SCREW-PAN-CROS,4X16 This part replaces 220C0416. Price: $1.81 |
| 11009 |
11009-1127 |
GASKET,FORK CYLINDER BOLT Price: $5.18 |
| 16126 |
16126-1265 |
VALVE,AIR Price: $51.62 |
| 44005 |
44005-1314 |
PIPE-LEFT FORK OUTER Price: $247.34 |
| 44006 |
44006-1311 |
PIPE-RIGHT FORK OUTER Price: $247.34 |
| 44013 |
44013-1360 |
PIPE-FORK INNER Price: $247.34 |
| 44022 |
44023-1108 |
CYLINDER-COMP-FORK This part replaces 44022-1271. Price: $93.31 |
| 44026D |
44026-1631 |
SPRING-FRONT FORK Price: $51.76 |
| 44028 |
44028-1059 |
GUIDE-FORK SPRING Price: $8.72 |
| 44028A |
44028-1068 |
GUIDE-FORK SPRING Price: $8.72 |
| 44037 |
44037-1293 |
HOLDER-FORK UNDER Price: $380.45 |
| 44039 |
44039-1220 |
HOLDER-FORK UPPER Price: $163.64 |
| 44065 |
44065-1106 |
BUSHING-FRONT FORK Price: $20.51 |
| 44065A |
44065-1107 |
BUSHING-FRONT FORK,IN Price: $18.86 |
| 44070A |
44070-1545 |
DAMPER-ASSY,FORK Price: $966.47 |
| 49006 |
49006-1273-VW |
BOOT,FORK,VIOLET Price: $43.30 |
| 49116 |
49116-1098 |
VALVE-ASSY,FORK Price: $124.25 |
| 92001 |
92001-1309 |
BOLT,FORK CYLINDER Price: $7.62 |
| 92009 |
92009-1568 |
SCREW Price: $7.21 |
| 92015 |
92210-1521 |
NUT,STEERING STEM,22MM This part replaces 92015-1653. Price: $16.69 |
| 92022 |
92022-1262 |
WASHER,FORK OUTER PIPE This part replaces 92022-1242. Price: $8.60 |
| 92022A |
92022-1873 |
WASHER,STEERING STEM Price: $7.45 |
| 92033 |
92033-1047 |
RING-SNAP,FORK Price: $6.46 |
| 92037 |
92037-1321 |
CLAMP, BOOT, BLACK Price: $9.52 |
| 92049 |
92049-1180 |
SEAL-OIL,FRONT FORK Price: $22.14 |
| 92055A |
92055-1441 |
RING-O,2.8X6.6X1.9 Price: $2.93 |
| 92093 |
92093-1166 |
SEAL,FRONT FORK Price: $18.22 |
