| Ref | Part Number | Description |
|---|
| 120 |
120CA0620 |
BOLT-SOCKET,6X20 Price: $1.77 |
| 220 |
220AB0525 |
SCREW-PAN-CROS,5X25 Price: $3.52 |
| 220A |
220AB0535 |
SCREW-PAN-CROS,5X35 Price: $2.06 |
| 220B |
220AB0545 |
SCREW-PAN-CROS,5X45 Price: $2.06 |
| 236 |
236AB0410 |
SCREW-PAN-WSP-CROS,4X10 Price: $1.52 |
| 13042 |
13042-5001 |
WEIGHT,HANDLE Price: $51.69 |
| 13091 |
13091-1624 |
HOLDER,CLUTCH LEVER Price: $35.87 |
| 13280 |
13280-1160 |
HOLDER,CLUTCH LEVER Price: $47.20 |
| 27010 |
27010-0855 |
SWITCH,CLUTCH This part replaces 27010-0717. Price: $32.97 |
| 32099 |
32099-0049 |
CASE,THROTTLE Price: $28.34 |
| 46003 |
46003-0162 |
HANDLE,LH Price: $233.00 |
| 46003A |
46003-0163 |
HANDLE,RH Price: $233.00 |
| 46019 |
46019-0020 |
GRIP-ASSY,THROTTLE Price: $42.73 |
| 46075 |
46075-0068 |
GRIP,LH Price: $18.92 |
| 46076 |
46076-0126 |
LEVER-ASSY-GRIP,CLUTCH This part replaces 46076-0078. Price: $112.23 |
| 46091 |
46091-0116 |
HOUSING-ASSY-CONTROL,LH Price: $191.35 |
| 46091A |
46091-0171 |
HOUSING-ASSY-CONTROL,RH Price: $143.57 |
| 46092 |
46092-0006 |
LEVER-GRIP,CLUTCH Price: $18.69 |
| 92145 |
92145-1286 |
SPRING Price: $5.95 |
| 92150 |
92150-1090 |
BOLT,6MM Price: $7.45 |
| 92150A |
92150-1604 |
BOLT,SOCKET,8X30 Price: $5.78 |
| 92151 |
92151-1523 |
BOLT Price: $7.45 |
| 92152 |
92152-0103 |
COLLAR Price: $19.00 |
| 92153 |
92153-0907 |
BOLT,SOCKET,8X35 Price: $4.92 |
| 92153A |
92154-1902 |
BOLT,17X18 This part replaces 92153-1667. Price: $18.95 |
| 92170 |
92170-1577 |
CLAMP Price: $3.83 |
| 92172 |
92172-0183 |
SCREW,3X16 Price: $2.15 |
| 92172A |
92172-1060 |
SCREW,ADJUST NUT Price: $39.14 |
