| Ref | Part Number | Description |
|---|
| 1 |
35004-4005-6D |
FENDER-FR,BLACK Price: $15.50 |
| 1 |
35004-4005-8S |
FENDER-FR,RED Price: $16.14 |
| 1 |
92075-281 |
DAMPER,9X24X14 Price: $6.22 |
| 2 |
112BA0618 |
BOLT-UPSET This part replaces 112G0618. Price: $1.03 |
| 3 |
112BA0622 |
BOLT-UPSET This part replaces 112B0622. Price: $3.74 |
| 4 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
| 5 |
115BA0825 |
BOLT-SMALL-UPSET,8X25 This part replaces 115G0825. Price: $5.42 |
| 6 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 7 |
32065-4008 |
BRACKET Price: $5.79 |
| 8 |
323N0800 |
NUT,CAP,8M/M Price: $4.60 |
| 9 |
35022-4002-6D |
FENDER-RR,BLACK Price: $136.30 |
| 9 |
35022-4002-8S |
FENDER-RR,RED Price: $103.33 |
| 10 |
92200-2137 |
WASHER,8.5X26X1.6 This part replaces 92022-092. Price: $0.55 |
| 11 |
92027-102 |
COLLAR,8.8X12X10.7 Price: $1.08 |
| 12 |
92027-194 |
COLLAR,L=11.1 Price: $5.52 |
| 13 |
92075-013 |
DAMPER RUBB TANK FRNT Price: $5.47 |
| 14 |
92075-112 |
DAMPER Price: $4.31 |
| 16 |
11034-4062 |
BRACKET,FLAP Price: $10.86 |
| 17 |
11034-4063 |
BRACKET,FLAP Price: $11.38 |
| 18 |
35019-4004-6D |
FLAP,BLACK This part replaces 35019-4004. Price: $11.34 |
| 19 |
92009-1289 |
SCREW,6X20 Price: $4.31 |
| 20 |
92075-051 |
DAMPER Price: $3.92 |
| 21 |
92200-0283 |
WASHER,6.5X20X1.6 This part replaces 92022-125. Price: $1.40 |
