| Ref | Part Number | Description |
|---|
| 1 |
92161-1532 |
DAMPER,CHANGE PEDAL This part replaces 13157-004. Price: $6.24 |
| 2 |
13242-011 |
PEDAL ANY,GEAR CHANGE Price: $149.63 |
| 3 |
92043-069 |
PIN Price: $14.81 |
| 4 |
92022-1028 |
WASHER,8.5X13X1 Price: $3.92 |
| 5 |
482K5000 |
CIRCLIP 5MM Price: $2.96 |
| 6 |
13159-008 |
CONNECTOR,B Price: $22.05 |
| 7 |
92017-010 |
NUT,8MM Price: $8.41 |
| 8 |
92003-115 |
BOLT,CHNG PEDAL JOINT Price: $12.89 |
| 9 |
318N0800 |
NUT,8MM Price: $3.58 |
| 10 |
13159-007 |
CONNECTOR,A Price: $20.98 |
| 11 |
13158-011 |
LEVER-GEAR CHANGE Price: $138.15 |
| 12 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 19 |
13169-005 |
PLATE CHNG DRUM PSTON Price: $4.57 |
| 20 |
464H0600 |
WASHER LOCK 6MM Price: $0.68 |
| 21 |
212B0616 |
SCREW CNTSNK HD 6X16 Price: $1.71 |
| 23 |
13080-004 |
RUBBER CAP Price: $5.73 |
| 25 |
92026-068 |
SPACER Price: $5.55 |
| 26 |
92152-0582 |
COLLAR,12X18X11.5 This part replaces 92027-121. Price: $9.23 |
| 27 |
92081-1129 |
SPRING,TENSION Price: $9.43 |
| 28 |
92001-1455 |
BOLT,RETURN SPRING This part replaces 92001-1401. Price: $4.69 |
| 29 |
318AA0800 |
NUT-HEX-SMALL,8MM This part replaces 312B0800. Price: $0.59 |
| 30 |
92003-117 |
BOLT,CHANGE PEDAL Price: $21.12 |
| 31 |
92022-150 |
SHIM-KICK SHAFT,0.5T Price: $3.77 |
