BATTERY CASE

BATTERY CASE

Parts (25)

RefPart NumberDescription
130 130AA0612 BOLT-FLANGED,6X12 This part replaces 130D0612. Price: $0.68
130A 130BB0610 BOLT-FLANGED,6X10 This part replaces 130J0610. Price: $2.49
130B 130BB0614 BOLT-FLANGED,6X14 This part replaces 130J0614. Price: $2.49
130C 130BB0616 BOLT-FLANGED,6X16 This part replaces 130J0616. Price: $2.06
130D 130BB0620 BOLT-FLANGED,6X20 This part replaces 130J0620. Price: $0.46
130E 130BB0820 BOLT-FLANGED,8X20 This part replaces 130J0820. Price: $0.84
130F 130BB0825 BOLT-FLANGED,8X25 This part replaces 130J0825. Price: $4.45
11012 11012-1460 CAP Price: $11.38
11012A 11012-1657 CAP Price: $15.98
11046 11046-1987 BRACKET,FUEL PUMP Price: $14.09
11047 11047-1923 BRACKET,TAIL GRIP Price: $69.10
11047A 11047-1924 BRACKET,STORAGE CASE Price: $15.89
11047B 11047-1927 BRACKET,OIL COOLER Price: $52.38
11047C 11047-1928 BRACKET,IGNITION COIL Price: $18.39
11047D 11047-1929 BRACKET,IGNITION COIL Price: $18.39
11048 11048-1206 BRACKET,REGULATOR Price: $20.50
32099 32099-1142 CASE,STORAGE Price: $44.04
46075G 46075-1105 GRIP,FRAME,LH Price: $37.52
46075H 46075-1106 GRIP,FRAME,RH Price: $37.52
92001 92001-1826 BOLT,6X20 Price: $3.92
92002 92002-1442 BOLT,SOCKET,8X25 Price: $5.05
92015 92210-0004 NUT,FLANGED,8MM This part replaces 92015-1183. Price: $5.38
92037 92037-1875 CLAMP,HOSE Price: $11.49
92150 92150-1694 BOLT,6X30 Price: $4.31
92150A 92153-1621 BOLT,SOCKET,8X20 This part replaces 92150-1839. Price: $2.15
