| Ref | Part Number | Description |
|---|
| 110 |
110B0608 |
BOLT HEX HEAD 6X8 Price: $0.34 |
| 11009 |
44045-051 |
GASKET,FORK CYLINDER BOLT Price: $6.16 |
| 11009A |
44045-052 |
GASKET,DRAIN PLUG Price: $6.10 |
| 11012A |
11012-1696 |
CAP,FORK TOP Price: $26.22 |
| 44001A |
44001-1723 |
FORK-FRONT Price: $1,417.97 |
| 44005 |
44005-1231 |
PIPE-LEFT FORK OUTER Price: $448.70 |
| 44006 |
44006-1231 |
PIPE-RIGHT FORK OUTER Price: $448.70 |
| 44013 |
44013-1230 |
PIPE-FORK INNER Price: $375.24 |
| 44022 |
44022-1180 |
CYLINDER-FORK Price: $129.21 |
| 44026 |
44026-1301 |
SPRING-FRONT FORK,K=0 Price: $81.69 |
| 44029A |
44029-1135 |
SEAT-FORK SPRING Price: $56.16 |
| 44033 |
44033-1166 |
COVER-FORK Price: $61.04 |
| 44037 |
44037-1195 |
HOLDER-FORK UNDER This part replaces 44037-1175. Price: $348.20 |
| 44039 |
44039-1117 |
HOLDER-FORK UPPER Price: $272.73 |
| 44065 |
44065-1070 |
BUSHING-FRONT FORK Price: $27.10 |
| 44065A |
44065-1071 |
BUSHING-FRONT FORK,IN Price: $24.97 |
| 92001 |
92001-1063 |
BOLT,HEX HEAD,8X40 Price: $9.63 |
| 92001A |
92001-1454 |
BOLT Price: $9.63 |
| 92001B |
92001-1464 |
BOLT,FORK CYLINDER Price: $6.22 |
| 92001C |
92001-1486 |
BOLT,FLANGED,8X50 Price: $11.49 |
| 92015 |
92015-1398 |
NUT,8MM This part replaces 92015-1055. Price: $4.80 |
| 92022 |
92022-1703 |
WASHER,SPRING,8MM Price: $3.42 |
| 92022A |
92022-1704 |
WASHER,SPRING,10MM Price: $3.42 |
| 92022B |
92022-1713 |
WASHER,SPRING SEAT Price: $11.91 |
| 92026 |
92026-1254 |
SPACER,FORK Price: $11.91 |
| 92026A |
92026-1255 |
SPACER,FRONT FORK SPR Price: $26.86 |
| 92033 |
92033-1200 |
RING-SNAP,FORK Price: $6.63 |
| 92033A |
92033-1201 |
RING-SNAP Price: $5.17 |
| 92049 |
92049-1230 |
SEAL-OIL,FORK Price: $25.19 |
| 92055 |
92055-1309 |
RING-O,FORK SPRING SE Price: $6.15 |
| 92093 |
92093-1197 |
SEAL,FORK Price: $24.34 |
