| Ref | Part Number | Description |
|---|
| 3 |
16036-004 |
CAP CARBURETOR RUBBER Price: $49.12 |
| 4 |
550AA1210 |
PIN-COTTER,1.2X10 This part replaces 550D1210. Price: $2.65 |
| 5 |
16021-002 |
SCREW,THROTTLE STOP Price: $18.22 |
| 6 |
16022-005 |
SPRING THR STOP SCREW Price: $8.68 |
| 7 |
16006-012 |
SPRING THROTTLE VALVE Price: $16.03 |
| 8 |
16007-007 |
SPRING SEAT THRTL VLV Price: $9.35 |
| 9 |
16008-010 |
CIRCLIP Price: $9.21 |
| 10 |
16009-049 |
JET NEEDLE 5DJ19 Price: $30.76 |
| 11 |
16024-005 |
ROD THROTTLE VLV STOP Price: $2.93 |
| 12 |
16025-048 |
VALVE-THROTTLE CA2.0 Price: $90.26 |
| 13 |
16017-062 |
NEEDLE JET,0-4 Price: $28.89 |
| 14 |
16051-002 |
CLAMP SET CARB MOUNT Price: $14.33 |
| 15 |
16014-006 |
SCREW Price: $17.15 |
| 16 |
16022-007 |
SPRING,PILOT AIR SCREW Price: $8.13 |
| 17 |
16019-008 |
GASKET FLOAT CHAMBER Price: $43.88 |
| 19 |
16034-001 |
WASHER MAIN JET Price: $4.31 |
| 21 |
16031-023 |
FLOAT Price: $31.54 |
| 22 |
223AA0416 |
SCREW-PAN-WS-CROS,4X16 This part replaces 16033-009. Price: $0.68 |
| 23 |
16002-017 |
ADJUSTER,CABLE Price: $13.38 |
| 24 |
16003-004 |
NUT CABLE ADJUST LOCK Price: $7.34 |
| 25 |
16004-006 |
CAP MIXING CHAMBER Price: $16.28 |
| 26 |
16005-016 |
TOP MIXING CHAMBER Price: $12.92 |
| 27 |
49006-1235 |
BOOT,STARTER PLUNGER This part replaces 16036-005. Price: $11.27 |
| 28 |
16012-008 |
CAP STARTER PLUNGER Price: $7.44 |
| 29 |
16013-003 |
SPRING-PLUNGER Price: $6.16 |
| 30 |
16016-002 |
PLUNGER-ENRICHNER Price: $31.85 |
| 31 |
16032-008 |
PIN,FLOAT This part replaces 16032-003. Price: $6.57 |
| 32 |
16029-004 |
GASKET,FLOAT VALVE SEAT Price: $3.89 |
