| Ref | Part Number | Description |
|---|
| 120 |
120CA0830 |
BOLT-SOCKET,8X30 Price: $2.80 |
| 130 |
130BA0840 |
BOLT-FLANGED,8X40 Price: $1.98 |
| 11009 |
44045-057 |
GASKET,FORK CYLINDER This part replaces 11009-1325. Price: $4.86 |
| 44008 |
44008-0097 |
PIPE-FORK OUTER Price: $475.95 |
| 44008A |
44008-0098 |
PIPE-FORK OUTER Price: $475.95 |
| 44013 |
44013-0107 |
PIPE-FORK INNER Price: $352.37 |
| 44023 |
44023-0195 |
CYLINDER-SET-FORK Price: $181.51 |
| 44026 |
44026-0298 |
SPRING-FRONT FORK Price: $71.34 |
| 44029 |
44029-0005 |
SEAT-FORK SPRING Price: $44.62 |
| 44037 |
44037-0206 |
HOLDER-FORK UNDER Price: $614.87 |
| 44039 |
44039-0202 |
HOLDER-FORK UPPER Price: $321.22 |
| 44041 |
44041-040 |
BOLT,SOCKET,FORK CYLINDER Price: $6.57 |
| 44065 |
44065-0014 |
BUSHING-FRONT FORK,INNER TUBE Price: $29.57 |
| 44065A |
44065-1115 |
BUSHING-FRONT FORK,OUTER TUBE Price: $28.71 |
| 44071 |
44071-1563 |
DAMPER-ASSY,FORK,LH Price: $766.97 |
| 44071A |
44071-1564 |
DAMPER-ASSY,FORK,RH Price: $766.97 |
| 49006 |
49006-0676 |
BOOT This part replaces 49006-0645. Price: $63.03 |
| 92022 |
92022-1298 |
WASHER,FORK OUTER TUBE Price: $8.58 |
| 92033 |
92033-1036 |
RING-SNAP Price: $6.51 |
| 92049 |
92049-1356 |
SEAL-OIL,FORK OUTER TUBE Price: $19.34 |
| 92055 |
92055-1321 |
RING-O Price: $0.74 |
| 92072 |
92072-1077 |
BAND,BOOT Price: $9.98 |
| 92093 |
92093-0036 |
SEAL,DUST Price: $20.49 |
| 92152 |
92152-0410 |
COLLAR,FORK Price: $14.80 |
| 92200 |
92200-1467 |
WASHER Price: $9.91 |
