| Ref | Part Number | Description |
|---|
| 10a |
518330738 |
Deep Black, RH Footrest Reinforcement Price: $88.99 |
| 10b |
518331523 |
Deep Black, LH Footrest Reinforcement This part replaces 518330737. Price: $88.99 |
| 10c |
518329627 |
RH Suspension Bracket Price: $81.99 |
| 10d |
518329628 |
LH Suspension Bracket Price: $81.99 |
| 10e |
518330072 |
RH Footrest Reinforcement Price: $19.99 |
| 10f |
518331560 |
Deep Black, LH Chasssis Reinforcement This part replaces 518329049. Price: $19.99 |
| 10g |
518329648 |
RH Roller Price: $194.99 |
| 10h |
518328452 |
LH Roller Price: $194.99 |
| 10j |
518334488 |
Radiator Tunnel 137 Ass'y This part replaces 415130269. Price: $739.99 |
| 10k |
250300027 |
Clinch Stud M6 X 20 Price: $2.09 |
| 10m |
518328990 |
Rear Cap Price: $22.49 |
| 10n |
518330691 |
RH Footrest Price: $25.99 |
| 10p |
518330692 |
LH Footrest Price: $24.99 |
| 10q |
293150203 |
Rivet Avibulb 3/16 Price: $2.19 |
| 10r |
293150144 |
Stavex Rivet Price: $0.84 |
| 10s |
293150096 |
Hemlock Rivet, 6.5 mm Price: $3.39 |
| 10t |
293150119 |
Hemlock Rivet, 6.5 mm Price: $4.39 |
| 10u |
293150174 |
Hemlock Rivet, 6.4 mm Price: $7.99 |
| 10v |
293150266 |
Ornit Rivet 6,5 X 14.5 This part replaces 293150147. Price: $2.49 |
| 20 |
293730052 |
Black, Plug Price: $9.19 |
| 25 |
250100199 |
Insert Half Hex Body M6 x 1.0 Price: $3.29 |
| 30 |
506151252 |
Washer Price: $3.29 |
| 70 |
250000942 |
Hex Screw M8 X 30 Price: $1.19 |
| 80 |
234081410 |
Flat Washer 8 mm Price: $0.82 |
| 90 |
233281414 |
Hex. Flange Elastic Nut M8 Price: $1.49 |
| 100b |
505073317 |
Leg Cushion Price: $8.66 |
| 100d |
505073317 |
Leg Cushion Price: $8.66 |
| 100e |
518331661 |
Bottom Plate This part replaces 518330074. Price: $37.99 |
| 100f |
293150203 |
Rivet Avibulb 3/16 Price: $2.19 |
| 100g |
293450268 |
Insert M5 X 0.8 Price: $2.09 |
| 100h |
207662046 |
Hex. Flange Screw M6 X 20 Price: $2.19 |
| 100j |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 Price: $1.49 |
| 110 |
293150266 |
Ornit Rivet 6,5 X 14.5 This part replaces 293150147. Price: $2.49 |
| 120 |
293150174 |
Hemlock Rivet, 6.4 mm Price: $7.99 |
| 125 |
293150120 |
Hemlock Rivet 6.5 mm Price: $7.59 |
| 130 |
130BA0610 |
BOLT-FLANGED,6X10 Price: $1.20 |
| 130 |
233281414 |
Hex. Flange Elastic Nut M8 Price: $1.49 |
| 130A |
130BA0822 |
BOLT-FLANGED,8X22 Price: $3.21 |
| 140 |
207662044 |
Hex. Flange Screw M6 X 20 Price: $2.09 |
| 150 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 Price: $1.49 |
| 170 |
293450268 |
Insert M5 X 0.8 Price: $2.09 |
| 180 |
207661644 |
Hex. Flange Screw M6 X 16 Price: $0.76 |
| 230 |
207562034 |
Hex. Flange Screw M6 X 20, Scotch Grip Price: $2.19 |
| 300a |
512061516 |
Vibration Damper This part replaces 512060295. Price: $62.99 |
| 310 |
250001060 |
Screw-Pan HD.Torx M8X30 Price: $0.84 |
| 400 |
518334549 |
Chassis Suspension Module Ass'y This part replaces 518330573. Price: $709.99 |
| 410 |
250001051 |
Screw-Forming Hex.HD.FL. M6 X 16 Price: $1.49 |
| 420 |
207663544 |
Hex. Flange Screw M6 X 35 Price: $0.92 |
| 430 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 Price: $1.49 |
| 440 |
293150266 |
Ornit Rivet 6,5 X 14.5 This part replaces 293150147. Price: $2.49 |
| 800 |
518329480 |
Member Fixation Plate Price: $12.99 |
| 815 |
293150203 |
Rivet Avibulb 3/16 Price: $2.19 |
| 900 |
518336882 |
Deep Black, LH Rear Diagonal Cross Member This part replaces 518329077. Price: $119.99 |
| 910 |
518330880 |
Black, RH Member Ass'y Price: $119.99 |
| 920 |
250000887 |
Pan Head Torx Screw M8 X 12 Price: $1.99 |
| 1000 |
250300629 |
Stud M5 X 20 Price: $2.09 |
| 1100 |
518329974 |
Upper Colomn Support Price: $22.49 |
| 1110 |
207562034 |
Hex. Flange Screw M6 X 20, Scotch Grip Price: $2.19 |
| 1115 |
293450275 |
Insert Price: $12.99 |
| 1120 |
233261414 |
Hex. Flange Elastic Nut M6 x 1.0 Price: $1.49 |
| 1125 |
233261416 |
Elastic Flange Nut M6 X 1.0 Price: $2.19 |
| 1130 |
207662544 |
Hex. Flange Screw M6 X 25 Price: $0.66 |
| 1140 |
207662044 |
Hex. Flange Screw M6 X 20 Price: $2.09 |
| 1300b |
250000779 |
Torx Screw M6 X 1.0 X 18, Scotch Grip Price: $2.19 |
| 1300c |
224061201 |
Flat Washer Price: $1.39 |
| 1400 |
293730047 |
Black, Dart 8 mm Price: $2.29 |
| 1405 |
293730060 |
Black, Dart 10 mm Price: $4.69 |
| 1700 |
518329982 |
Front Protector Price: $18.49 |
| 1710 |
293150108 |
Pop Rivet 3/16” This part replaces 293150108. Price: $1.19 |
| 1800a |
293830005 |
Rubber Bumper Price: $8.29 |
| 1820 |
520001545 |
Support Price: $2.09 |
| 1830 |
250000577 |
Torx Truss Screw K40 X 12 Price: $2.19 |
| 11055 |
11055-1929 |
BRACKET,FUEL TANK Price: $22.23 |
| 14093 |
14093-0263-18T |
COVER,PIVOT,LH,F.S.BLACK Price: $118.24 |
| 14093A |
14093-0264-18T |
COVER,PIVOT,RH,F.S.BLACK Price: $118.24 |
| 35063 |
35063-0967-18R |
STAY,STEP,LH,F.S.BLACK Price: $88.04 |
| 35063A |
35063-1376-18R |
STAY,STEP,RH,F.S.BLACK Price: $88.04 |
| 39156 |
39156-1921 |
PAD,18X8X4 Price: $1.84 |
| 39188 |
39188-0049 |
TAPE,40X50 Price: $2.73 |
| 46075 |
46075-0593-18R |
GRIP,TANDEM,LH,F.S.BLACK Price: $191.56 |
| 46075A |
46075-0594-18R |
GRIP,TANDEM,RH,F.S.BLACK Price: $191.56 |
| 53044 |
53044-1174 |
TRIM,L=40 Price: $4.31 |
| 55020 |
55020-0978 |
GUARD,STEP,LH Price: $7.51 |
| 55020A |
55020-0979 |
GUARD,STEP,RH,RR Price: $7.51 |
| 55020B |
55020-0980 |
GUARD,STEP,RH,FR Price: $3.91 |
| 92055 |
92055-0798 |
RING-O,62.6X3.5 Price: $2.70 |
| 92066 |
92066-1103 |
PLUG Price: $3.89 |
| 92066A |
92066-1306 |
PLUG Price: $5.46 |
| 92075 |
92075-1067 |
DAMPER Price: $4.69 |
| 92151 |
92151-1605 |
BOLT,SOCKET,6X30 Price: $2.34 |
| 92152 |
92152-0976 |
COLLAR,10.6X13.8X15 Price: $4.10 |
| 92152A |
92152-1997 |
COLLAR,6.5X10X19.1 Price: $3.54 |
| 92154 |
92154-0842 |
BOLT,SOCKET,8X30 Price: $4.10 |
| 92154A |
92154-1292 |
BOLT,SOCKET,5X10 Price: $1.48 |
| 92160 |
92160-1272 |
DAMPER Price: $5.29 |
| 92160A |
92160-1613 |
DAMPER Price: $3.74 |
| 92161 |
92161-0946 |
DAMPER,14X26X13.9 Price: $1.63 |
