| Ref | Part Number | Description |
|---|
| 2 |
411AA1200 |
WASHER-PLAIN,12MM This part replaces 411B1200. Price: $0.96 |
| 3 |
92027-1477 |
COLLAR,12.2X22X28.5 This part replaces 42032-006. Price: $9.81 |
| 4 |
42006-066-80 |
PANEL-ASY,RR BRK,BUFF Price: $120.68 |
| 5 |
112BA0630 |
BOLT-UPSET This part replaces 112G0630. Price: $1.38 |
| 6 |
42029-020 |
LEVER-REAR BRAKE CAM Price: $35.71 |
| 7 |
41072-007 |
NUT,6MM Price: $3.92 |
| 8 |
41085-003 |
INDICATOR,BKSHOE Price: $14.51 |
| 10 |
42026-018 |
CAM SHAFT,REAR BRAKE Price: $33.87 |
| 11 |
41048-1085 |
SHOE-BRAKE Price: $22.53 |
| 12 |
92081-1766 |
SPRING,BRAKE SHOE Price: $8.03 |
| 13 |
41034-1039 |
DRUM-ASSY,RR This part replaces 42005-031-80. Price: $211.80 |
| 14 |
601B6301Z |
BEARING BALL #6301Z Price: $20.51 |
| 15 |
42010-005 |
SPACER-RR HUB BEARING Price: $12.76 |
| 16 |
601B6201 |
BEARING-BALL,#6201C3 Price: $10.98 |
| 17 |
42014-016 |
DAMPER REAR HUB SHOCK Price: $18.41 |
| 18 |
92151-1160 |
BOLT This part replaces 92001-082. Price: $2.98 |
| 19 |
42033-014 |
COUPLING ASSY-RR HUB Price: $117.57 |
| 20 |
42036-013 |
SLEEVE-RR HUB COUPLNG Price: $39.30 |
| 21 |
601B6203 |
BEARING BALL #6203 Price: $14.12 |
| 22 |
92052-003 |
OIL SEAL-COUPLING Price: $13.38 |
| 23 |
42037-003 |
BUSH,COUPLNG OIL SEAL Price: $13.71 |
| 24 |
42045-004 |
NUT,16MM Price: $8.60 |
| 25 |
42041-104 |
RR SPROCKET 39T (OPT) Price: $51.23 |
| 25 |
42041-1095 |
SPROCKET-HUB,40T Price: $48.87 |
| 26 |
92088-011 |
WASHER LOCK Price: $5.11 |
| 27 |
315AA1000 |
NUT-HEX-FINE,10MM This part replaces 315B1000. Price: $0.59 |
| 28 |
42045-005 |
NUT 10MM Price: $7.98 |
| 29 |
92057-1085 |
CHAIN,DRIVE,EK428-G Price: $103.52 |
