| Ref | Part Number | Description |
|---|
| 1 |
93700-06002-00 |
NIPPLE, GREASE Price: $8.55 |
| 2 |
90465-08M83-00 |
CLAMP Price: $7.70 |
| 3 |
97885-06012-00 |
SCREW, PAN HEAD This part replaces 97985-06212-00. Price: $3.35 |
| 4 |
90465-10098-00 |
CLAMP This part replaces 90465-11M10-00. Price: $2.70 |
| 5 |
90465-08M83-00 |
CLAMP Price: $7.70 |
| 6 |
97585-06510-00 |
BOLT, WITH WASHER Price: $1.25 |
| 7 |
90119-10024-00 |
BOLT, WITH WASHER Price: $10.40 |
| 8 |
6KA-4382A-00-00 |
ADAPTOR 1 Price: $28.40 |
| 9 |
97595-05516-00 |
BOLT, WITH WASHER Price: $1.55 |
| 10 |
6GR-85887-00-00 |
SENSOR ANGLE Price: $101.05 |
| 11 |
93210-17MF9-00 |
O-RING Price: $8.49 |
| 12 |
97595-05516-00 |
BOLT, WITH WASHER Price: $1.55 |
| 13 |
6LF-82553-00-00 |
EXTENSION, WIRE LEAD Price: $44.00 |
| 14 |
6KA-43126-00-00 |
PIN, UPPER SHOCK MOUNT Price: $99.55 |
| 15 |
91690-60022-00 |
PIN, SPRING Price: $2.75 |
| 16 |
93210-06ME6-00 |
O-RING Price: $3.55 |
| 17 |
90386-18M14-00 |
BUSH Price: $10.40 |
| 18 |
6AW-43376-00-00 |
BOLT, THRUST RECEIVER Price: $39.80 |
| 19 |
95780-10300-00 |
NUT, FLANGE Price: $13.00 |
| 20 |
6KF-42829-00-00 |
PLATE, CLAMP 2 Price: $10.70 |
| 21 |
97585-06510-00 |
BOLT, WITH WASHER Price: $1.25 |
| 22 |
6KF-42828-00-00 |
PLATE, CLAMP Price: $52.40 |
