Generator
Parts (52)
| Ref | Part Number | Description |
|---|---|---|
| 2 | 507032476 | Lever With Parking Lock Price: $104.99 |
| 3 | 507032477 | Clamp And Screw Kit Price: $23.99 |
| 5 | 415129356 | Screw M4 X 20 Price: $2.29 |
| 6 | 415030000 | Pin Ass'y Price: $19.99 |
| 7 | 507032479 | Microswitch Price: $104.99 |
| 8 | 515175232 | Male Terminal Price: $1.59 |
| 9 | 414920500 | Banjo Bolt Price: $8.89 |
| 10 | 414920600 | Washer Price: $1.90 |
| 12 | 507032473 | Brake Pads Kit This part replaces 507032486. Price: $52.99 |
| 13 | 507032722 | Brake Spring Kit This part replaces 507032474. Price: $38.99 |
| 14 | 507032475 | Bleeder Price: $19.99 |
| 15 | 414989700 | BOOT-QTS 20 - Call your local BRP dealership Price: $22.49 |
| 16 | 250000764 | Hex. Button Head Screw M8 X 1.25 X 35 This part replaces 250000301. Price: $2.09 |
| 17 | 414920500 | Banjo Bolt Price: $8.89 |
| 18 | 414920600 | Washer Price: $1.90 |
| 19 | 507032487 | Disc Price: $185.49 |
| 20 | 219704461 | LUBRICANT LOCTITE LB 8150 236ML - Call your local BRP dealership Price: $25.99 |
| 21 | 293300134 | O-Ring Price: $2.39 |
| 22 | 507032446 | Aluminum Disk Protector Price: $28.99 |
| 23 | 250000312 | TORX SCREW M6 X 16 - Call your local BRP dealership Price: $1.89 |
| 24 | 507032497 | Threaded Tube This part replaces 507032469. Price: $15.72 |
| 25 | 250000223 | Torx Screw M6 X 16 Price: $2.19 |
| 26 | 507032481 | Hose Price: Call Us |
| 13272 | 13272-2135 | PLATE,RETAINER Price: $11.00 |
| 13280 | 13280-0864 | HOLDER Price: $252.61 |
| 13280A | 13280-0865 | HOLDER,BRUSH Price: $55.96 |
| 14093 | 14093-0450 | COVER Price: $5.56 |
| 14093A | 14093-0451 | COVER Price: $110.64 |
| 21001 | 21001-0613 | GENERATOR Price: $1,392.12 |
| 21007 | 21007-0637 | ROTOR Price: $368.27 |
| 21066 | 21066-0749 | REGULATOR-VOLTAGE Price: $464.74 |
| 31011 | 31011-0027 | FRAME Price: $418.19 |
| 31011A | 31011-0028 | FRAME Price: $104.79 |
| 43094 | 43094-0007 | ADJUSTER Price: $24.25 |
| 59091 | 59091-0015 | PULLEY Price: $75.51 |
| 92004 | 92004-0751 | STUD Price: $11.59 |
| 92026 | 92026-0821 | SPACER Price: $9.07 |
| 92045 | 92045-0812 | BEARING-BALL Price: $23.79 |
| 92045A | 92045-0816 | BEARING-BALL Price: $29.60 |
| 92139 | 92139-0861 | BUSHING Price: $15.26 |
| 92152 | 92152-2198 | COLLAR Price: $17.78 |
| 92154 | 92154-2074 | BOLT Price: $3.98 |
| 92154A | 92154-2075 | BOLT Price: $4.78 |
| 92154B | 92154-2076 | BOLT,FLANGED,10X45 Price: $3.35 |
| 92154C | 92154-2077 | BOLT Price: $15.80 |
| 92154D | 92154-2078 | BOLT,FLANGED,8X20 Price: $2.03 |
| 92172 | 92172-0989 | SCREW Price: $3.94 |
| 92172A | 92172-0990 | SCREW Price: $3.94 |
| 92172B | 92172-0991 | SCREW Price: $3.35 |
| 92172C | 92172-1096 | SCREW Price: $3.98 |
| 92210 | 92210-1474 | NUT Price: $5.61 |
| 92210A | 92210-1475 | NUT Price: $3.98 |
