| Ref | Part Number | Description |
|---|
| 11009 |
11009-1147 |
GASKET,FLOAT CHAMBER Price: $10.19 |
| 11009A |
16029-004 |
GASKET,FLOAT VALVE SEAT Price: $3.89 |
| 16001 |
16001-1548 |
CARBURETOR Price: $176.65 |
| 16002 |
16002-017 |
ADJUSTER,CABLE Price: $13.38 |
| 16004 |
16004-025 |
CAP-CHAMBER Price: $33.28 |
| 16007 |
16007-023 |
SEAT-SPRING,THROTTLE VALVE Price: $10.19 |
| 16009 |
16009-1128 |
NEEDLE-JET,5113-2 Price: $22.71 |
| 16016 |
16016-1027 |
PLUNGER Price: $36.03 |
| 16017 |
16017-1123 |
JET-NEEDLE,0-2 Price: $21.65 |
| 16021 |
16021-1042 |
SCREW-THROTTLE STOP Price: $14.21 |
| 16025 |
16025-1028 |
VALVE,THROTTLE,C.A1.5 Price: $137.62 |
| 16030 |
16030-005 |
FLOAT VALVE ASSY Price: $58.86 |
| 16031 |
16031-1005 |
FLOAT Price: $53.59 |
| 16049 |
16049-1001 |
COVER-MAIN JET Price: $26.99 |
| 16065 |
16065-1020 |
HOLDER,JET NEEDLE Price: $18.54 |
| 49006 |
16036-007 |
CAP,CARBURETOR Price: $17.80 |
| 92015 |
16003-006 |
NUT,ADJUST LOCK Price: $7.34 |
| 92037 |
16008-010 |
CIRCLIP Price: $9.21 |
| 92037A |
92037-072 |
CLAMP-PIPE Price: $7.22 |
| 92043 |
16032-008 |
PIN,FLOAT This part replaces 16032-003. Price: $6.57 |
| 92055 |
92055-044 |
RING-O Price: $10.38 |
| 92055A |
92055-1061 |
RING-O,MAIN JET COVER Price: $8.58 |
| 92059 |
92059-1755 |
TUBE,3X5X300 Price: $9.24 |
| 92059A |
92059-1129 |
TUBE,5.3X10.5X150 Price: $21.98 |
| 92063 |
92063-1102 |
JET-MAIN,#A125 This part replaces 92063-055. Price: $14.10 |
| 92063A |
92063-1100 |
JET-MAIN,#A127.5 Price: $14.10 |
| 92063B |
92063-1103 |
JET-MAIN,#A130 This part replaces 92063-057. Price: $14.10 |
| 92063C |
92063-1106 |
JET-MAIN,#A120 This part replaces 92063-078. Price: $18.50 |
| 92063D |
92063-1101 |
JET-MAIN,#A122.5 Price: $14.10 |
| 92064 |
92064-1060 |
JET-PILOT,#45 Price: $10.34 |
| 92081 |
16006-023 |
SPRING,THROTTLE VALVE Price: $15.02 |
| 92081A |
92081-1152 |
SPRING,THROTTLE ADJUST Price: $6.16 |
