| Ref | Part Number | Description |
|---|
| 1 |
44001-177 |
FORK-FRONT Price: $920.30 |
| 2 |
44041-037 |
BOLT-FORK FITTING Price: $42.23 |
| 3 |
92055-1012 |
O RING,FORK TOP Price: $8.50 |
| 4 |
44039-051 |
HEAD-STEERING STEM Price: $137.75 |
| 5 |
461DA0800 |
WASHER-SPRING,8MM This part replaces 461F0800. Price: $0.40 |
| 6 |
44041-044 |
BOLT-STEERING STEM HD Price: $9.20 |
| 7 |
44041-042 |
BOLT-STEERING STEM HD Price: $5.13 |
| 8 |
92015-1124 |
NUT,LOCK,8MM Price: $5.42 |
| 9 |
44045-039 |
GASKET,FORK COVER Price: $5.21 |
| 10 |
44043-047 |
WASHER,FORK COVER Price: $12.15 |
| 11 |
44033-067 |
COTER,L.H FORK Price: $86.30 |
| 12 |
44034-067 |
COVER,R.H FORK Price: $86.30 |
| 13 |
44032-005 |
CAP,FORK COVER Price: $8.56 |
| 14 |
44045-029 |
GASKET FORK COVER Price: $5.21 |
| 15 |
44064-015 |
GUIDE,FORK COVER Price: $30.50 |
| 16 |
44037-097 |
STEM,STEERING Price: $170.37 |
| 17 |
461DA1000 |
WASHER-SPRING,10MM This part replaces 461F1000. Price: $0.68 |
| 19 |
44028-026 |
SPACER-FORK SP GUIDE Price: $12.63 |
| 20 |
44029-019 |
GUIDE-FORK SPRING Price: $8.55 |
| 21 |
44026-043 |
SPRING-FORK Price: $67.13 |
| 22 |
44013-038 |
TUBE-FORK INNER Price: $548.59 |
| 23 |
44022-034 |
CYLINDER-FORK Price: $72.78 |
| 24 |
44018-009 |
PISTON,FORK Price: $25.98 |
| 25 |
44044-019 |
CIRCLIP,FORK PISTON Price: $7.96 |
| 26 |
44010-035 |
DUST SHIELD Price: $57.82 |
| 27 |
44044-005 |
CIRCLIP OIL SEAL FIT Price: $9.20 |
| 28 |
44043-023 |
WASHER OIL SEAL FIT Price: $3.76 |
| 29 |
44009-026 |
OIL SEAL Price: $60.50 |
| 30 |
44005-061 |
TUBE,LH,FORK OUTER Price: $317.84 |
| 31 |
44006-059 |
TUBE,RH,FORK OUTER Price: $367.80 |
| 32 |
44045-002 |
GASKET,FORK DRAIN PLUG Price: $5.18 |
| 33 |
220AA0408 |
SCREW-PAN-CROS,4X8 This part replaces 220B0408. Price: $0.68 |
| 34 |
44045-057 |
GASKET,FORK CYLINDER Price: $4.86 |
| 35 |
44041-040 |
BOLT,SOCKET,FORK CYLINDER Price: $6.57 |
| 36 |
172BA0830 |
BOLT-STUD,8X30 This part replaces 172G0830. Price: $2.56 |
| 37 |
44063-012 |
HOLDER,FRONT AXLE Price: $20.08 |
| 38 |
92007-031 |
BOLT,STEERG STEM HEAD Price: $29.84 |
| 39 |
92200-1273 |
WASHER,16X41X4.5 This part replaces 92022-230. Price: $11.93 |
| 40 |
46100-003 |
WASHER,WAVE Price: $11.39 |
| 41 |
92090-007 |
NUT,30MM Price: $11.71 |
| 42 |
46098-016 |
CAP,STEERING STEM Price: $6.51 |
| 43 |
92047-006 |
CONE STRNG STEM BERNG Price: $12.67 |
| 44 |
92037-099 |
CLAMP-CABLE Price: $6.65 |
| 45 |
411AA0600 |
WASHER-PLAIN,6MM This part replaces 411B0600. Price: $2.92 |
| 46 |
461DA0600 |
WASHER-SPRING,6MM This part replaces 461F0600. Price: $0.71 |
