| Ref | Part Number | Description |
|---|
| 11009 |
11009-3036 |
GASKET Price: $10.83 |
| 11009A |
16029-004 |
GASKET,FLOAT VALVE SEAT Price: $3.89 |
| 11009B |
92065-078 |
GASKET-BANJO BOLT Price: $1.09 |
| 11009C |
92065-526 |
GASKET Price: $15.19 |
| 11009D |
92065-528 |
WASHER Price: $2.18 |
| 11012 |
11012-3739 |
CAP,JET NEEDLE Price: $7.58 |
| 11034 |
59086-541 |
PLATE-CARB. SIDE Price: $14.92 |
| 11060 |
11060-3704 |
GASKET Price: $10.87 |
| 11060A |
11060-3705 |
GASKET Price: $11.12 |
| 11060B |
11060-3706 |
GASKET Price: $10.34 |
| 13169 |
59001-506 |
ARM Price: $17.93 |
| 14024 |
59036-530 |
COVER-CARB. SIDE Price: $14.79 |
| 14037 |
14037-504 |
FILTER Price: $15.93 |
| 15001 |
15001-3761 |
CARBURETOR-ASSY Price: $573.35 |
| 16009 |
16009-3709 |
NEEDLE-JET,HIGH SPEED Price: $39.19 |
| 16009A |
16009-3710 |
NEEDLE-JET Price: $33.13 |
| 16030 |
16030-503 |
VALVE-SEAT Price: $53.47 |
| 21169 |
21169-3008 |
TERMINAL,CHOKE SHAFT Price: $26.44 |
| 32099 |
59021-514 |
BODY,DIAPHRAGM(1) Price: $140.05 |
| 39074 |
39074-3704 |
LEVER-ASSY-THROTTLE,T Price: $45.84 |
| 39075 |
39075-3706 |
LEVER-THROTTLE Price: $26.63 |
| 43028 |
43028-3001 |
DIAPHRAGM,PUMP Price: $10.48 |
| 43028A |
43028-3002 |
DIAPHRAGM,PUMP Price: $10.48 |
| 43028B |
51069-501 |
DIAPHRAGM,CHECK SEAT Price: $9.65 |
| 43028C |
51069-502 |
DIAPHRAGM,MAIN Price: $8.87 |
| 59071 |
59071-505 |
BANJO-CARB Price: $29.91 |
| 59336 |
59336-3002 |
BODY,DIAPHRAGM(2) Price: $95.87 |
| 59336A |
59336-3003 |
BODY,DIAPHRAGM(3) Price: $77.43 |
| 92001 |
92001-3026 |
BOLT,4X8 Price: $7.89 |
| 92001A |
92003-521 |
BOLT,BANJO Price: $26.94 |
| 92009 |
92009-2245 |
SCREW,4X18 Price: $7.65 |
| 92009A |
92009-3714 |
SCREW Price: $2.42 |
| 92009B |
92011-510 |
SCREW 4X12 Price: $7.65 |
| 92015 |
92015-3717 |
NUT,THROTTLE LEVER Price: $6.41 |
| 92022 |
92022-3020 |
WASHER,PLAIN,6NYLON Price: $5.33 |
| 92022A |
92022-3722 |
WASHER,THROTTLE LEVER Price: $4.18 |
| 92022B |
92022-537 |
WASHER Price: $4.53 |
| 92027 |
92027-3709 |
COLLAR,THROTTLE SHAFT Price: $29.41 |
| 92028 |
92028-3730 |
BUSH Price: $24.93 |
| 92033 |
92033-3004 |
CIRCLIP,5M/M,SUS304 Price: $2.20 |
| 92043 |
16032-006 |
FLOAT PIN Price: $7.29 |
| 92081 |
92081-528 |
SPRING Price: $6.22 |
| 92081A |
92081-534 |
SPRING Price: $6.22 |
| 92081B |
92081-536 |
SPRING Price: $4.53 |
| 92144 |
99996-1116 |
SPRING/BUSHING SET This part replaces 92144-3715. Price: $32.28 |
| 92144A |
92144-3722 |
SPRING Price: $9.22 |
| 92150 |
92150-3757 |
BOLT Price: $11.10 |
