| Ref | Part Number | Description |
|---|
| 750 |
270001130 |
Engine Cover Price: $74.99 |
| 755 |
293730112 |
Snap Fastener Price: $2.19 |
| 1070a |
250000888 |
Hexagonal Screw M8 X 30 Price: $3.29 |
| 1100 |
270001215 |
Front Engine Support Ass'y Price: $99.99 |
| 1110 |
250200018 |
Cone Washer Price: $5.69 |
| 1120 |
250000782 |
Hexagonal Head Cap Screw M8 X 45 Price: $2.89 |
| 1150 |
270000762 |
Shim 1.3 mm Price: $12.99 |
| 1570a |
250000888 |
Hexagonal Screw M8 X 30 Price: $3.29 |
| 1600 |
270001211 |
Lateral Engine Support Ass'y Price: $109.99 |
| 1610 |
250200018 |
Cone Washer Price: $5.69 |
| 1620 |
250000782 |
Hexagonal Head Cap Screw M8 X 45 Price: $2.89 |
| 1650 |
270000762 |
Shim 1.3 mm Price: $12.99 |
| 1820a |
250000888 |
Hexagonal Screw M8 X 30 Price: $3.29 |
| 1850 |
270001211 |
Lateral Engine Support Ass'y Price: $109.99 |
| 1860 |
250200018 |
Cone Washer Price: $5.69 |
| 1870 |
250000782 |
Hexagonal Head Cap Screw M8 X 45 Price: $2.89 |
| 1900 |
270000762 |
Shim 1.3 mm Price: $12.99 |
| 2000a |
273000422 |
Lower Intake Silencer Price: $71.99 |
| 2000b |
273000423 |
Upper Intake Silencer Price: $71.99 |
| 2000c |
273000424 |
Intake Duct Silencer Int Price: $49.99 |
| 2000d |
273000428 |
Intake Duct Silencer Out Price: $45.99 |
| 2000f |
273000425 |
Intake Duct Silencer In Price: $48.99 |
| 2000g |
219903177 |
Air Silencer Notice Decal Price: $0.01 |
| 2000h |
708003866 |
Seat Stopper Price: $4.69 |
| 2000j |
293730040 |
Mount Dart Price: $1.09 |
| 2300 |
270000950 |
Formed Hose Price: $10.99 |
| 2305 |
273000234 |
Breather Valve Price: $14.99 |
| 2310 |
293650284 |
Gear Clamp Price: $4.49 |
| 2315 |
293650284 |
Gear Clamp Price: $4.49 |
| 2350 |
273000426 |
Central Intake Duct Price: $48.99 |
| 2370 |
273000431 |
Duct Support Price: $48.99 |
| 2380 |
241152060 |
Hex. Flange Screw K50 X 20 Price: $1.99 |
| 2385 |
273000437 |
Retaining Strap Price: $15.35 |
| 2410 |
293650244 |
Tridon Gear Clamp Price: $9.29 |
| 2420 |
273000427 |
Molded Compressor Hose IN Price: $30.49 |
| 2430 |
293650179 |
Tridon Clamp Price: $11.49 |
| 3000a |
271001942 |
Anode Zinc Price: $18.76 |
| 3010 |
273000420 |
Formed Compressor Hose Out Price: $76.49 |
| 3020 |
293650244 |
Tridon Gear Clamp Price: $9.29 |
| 3025 |
293650179 |
Tridon Clamp Price: $11.49 |
| 3030 |
273000449 |
Formed Throttle Body Hose IN Price: $92.99 |
| 3035 |
273000448 |
Intake Duct Price: $20.99 |
| 3037 |
273000469 |
Duct Fitting Price: $28.99 |
| 3040 |
293650244 |
Tridon Gear Clamp Price: $9.29 |
| 3045 |
293650179 |
Tridon Clamp Price: $11.49 |
| 3070 |
293850094 |
Fuel Tank Strap Price: $22.49 |
| 3075 |
293850093 |
Fuel Tank Strap Price: $21.99 |
| 3550 |
250000287 |
Flange Torx Screw K40 X 16 Price: $2.19 |
| 4000 |
273000453 |
Purge Valve Price: $224.99 |
| 4010 |
219704352 |
Was 420660574 Pressure Hose 280 mm Price: $229.99 |
| 4020 |
273000450 |
Formed Check Valve Hose Price: $12.99 |
| 4025 |
293650323 |
Gear Clamp Price: $4.44 |
| 4030 |
293650323 |
Gear Clamp Price: $4.44 |
