| Ref | Part Number | Description |
|---|
| 1 |
220AA0512 |
SCREW-PAN-CROS,5X12 This part replaces 220B0512. Price: $0.47 |
| 2 |
14065-001 |
HOLDER-CARBURETOR CAP Price: $7.37 |
| 3 |
14038-034 |
CAP,CARBURETOR Price: $18.56 |
| 4 |
220AA0655 |
SCREW-PAN HEAD,6X55 This part replaces 220B0655. Price: $4.12 |
| 5 |
220AA0635 |
SCREW-PAN-CROS,6X35 This part replaces 220B0635. Price: $1.63 |
| 6 |
92074-021 |
RUBBER PLUG-CARB CAP Price: $2.50 |
| 7 |
14031-038-21 |
COVER-LH ENG,BLACK Price: $63.61 |
| 8 |
14026-005-21 |
COVER-CHN CASE,BLACK Price: $49.59 |
| 9 |
14040-003 |
CAP-CLUTCH HOLE Price: $4.68 |
| 10 |
14045-008 |
GASKET-L.H ENG COVER Price: $11.56 |
| 11 |
220AA0625 |
SCREW-PAN-CROS,6X25 This part replaces 220B0625. Price: $2.78 |
| 12 |
14018-004 |
HOLDER-TACHOMETER GR Price: $21.60 |
| 13 |
610A0512 |
PIN DOWEL 5X12 Price: $4.78 |
| 14 |
92054-004 |
OIL SEAL Price: $25.02 |
| 15 |
92055-025 |
RING-O,12X1.5 Price: $4.69 |
| 16 |
92028-075 |
BUSH Price: $22.07 |
| 17 |
13223-004 |
GEAR-TACHOMETER Price: $26.14 |
| 18 |
13224-006 |
PINION-TACHOMETER Price: $41.29 |
| 19 |
510A3100 |
KEY-WOODRUFF Price: $2.70 |
| 21 |
92026-025 |
WASHER THRUST Price: $7.55 |
| 22 |
14046-020 |
GASKET-R.H-ENG.CVR Price: $13.46 |
| 23 |
14032-090-21 |
COVER,R.H ENG,F.BLACK Price: $207.40 |
| 24 |
16136-006 |
GROMMET-OVERFLOW PIPE Price: $3.01 |
| 25 |
92065-058 |
GASKET,10.5X16X1 Price: $3.96 |
| 26 |
92067-001 |
PLUG,DRAIN,10X12 Price: $4.41 |
| 27 |
16116-001 |
PIPE FUEL OVERFLOW Price: $6.72 |
| 28 |
92049-012 |
OIL SEAL SB20285 Price: $10.89 |
| 29 |
220AA0630 |
SCREW-PAN-CROS,6X30 This part replaces 220B0630. Price: $3.67 |
| 30 |
14044-005 |
HOLDER-OIL PUMP CABLE Price: $4.64 |
| 31 |
92036-017 |
CIRCLIP Price: $3.25 |
| 32 |
220AA0620 |
SCREW-PAN-CROS,6X20 This part replaces 220B0620. Price: $5.82 |
| 33 |
16065-010 |
HOLDER-CARBURETOR Price: $16.24 |
| 34 |
220AA0612 |
SCREW-PAN-CROS,6X12 This part replaces 220B0612. Price: $1.19 |
| 35 |
220AA0670 |
SCREW-PAN HEAD,6X70 This part replaces 220B0670. Price: $4.12 |
| 36 |
14064-001 |
STOPPER-CARBURETOR Price: $1.59 |
| 37 |
16115-017 |
PLUG-OIL FILLER Price: $16.67 |
| 38 |
670B2020 |
O RING,20MM Price: $1.22 |
| 39 |
11060-1477 |
GASKET,CARBURETOR CVR This part replaces 14048-002. Price: $39.19 |
| 40 |
14030-034-21 |
COVER-CARB,F.BLACK Price: $102.55 |
| 41 |
92067-006 |
PLUG-CARBURETOR COVER Price: $48.86 |
