Cylinder Head Cover
Parts (31)
| Ref | Part Number | Description |
|---|---|---|
| 10a | 507032476 | Lever With Parking Lock Price: $104.99 |
| 10ca | 415129356 | Screw M4 X 20 Price: $2.29 |
| 10d | 415030000 | Pin Ass'y Price: $19.99 |
| 10e | 507032601 | Microswitch Price: $74.99 |
| 10f | 414439000 | Circlip Price: $4.29 |
| 12 | 250000447 | Hex. Flange Screw M6 X 25 Price: $2.19 |
| 30 | 507032551 | Banjo Bolt Price: $5.61 |
| 40 | 414920600 | Washer Price: $1.90 |
| 200a | 507032473 | Brake Pads Kit Price: $52.99 |
| 200b | 507032722 | Brake Spring Kit This part replaces 507032474. Price: $38.99 |
| 200c | 507032475 | Bleeder Price: $19.99 |
| 210 | 250000764 | Hex. Button Head Screw M8 X 1.25 X 35 Price: $2.09 |
| 230 | 507032551 | Banjo Bolt Price: $5.61 |
| 240 | 414920600 | Washer Price: $1.90 |
| 400 | 507032554 | Disk Price: $222.49 |
| 420 | 293300221 | O Ring Price: $1.69 |
| 500a | 507032639 | Disc Protector Price: $63.99 |
| 510 | 250000767 | Torx Truss Screw M6 X 12 Price: $2.09 |
| 520 | 233261466 | Hex. Flange Elastic Nut M6 Price: $2.09 |
| 600 | 507032655 | Brake Hose Price: $62.49 |
| 610 | 414108400 | Open Clamp Price: $3.29 |
| 620 | 210261040 | Hex. Flange Screw M6 X 10 Price: $1.49 |
| 625 | 293650257 | Hose Clamp Price: $6.09 |
| 11061 | 11061-0738 | GASKET,HEAD COVER Price: $61.36 |
| 11061A | 11061-0977 | GASKET,HEAD HOLE Price: $12.86 |
| 11065 | 11065-1247 | CAP Price: $29.99 |
| 12021 | 12021-1130 | VALVE-ASSY-REED Price: $79.29 |
| 14091 | 14091-1574 | COVER,HEAD Price: $263.70 |
| 92043 | 92043-4009 | PIN,10.1X12X14 Price: $6.22 |
| 92055 | 92055-0187 | RING-O Price: $5.54 |
| 92153 | 92153-1016 | BOLT,FLANGED,6X22.5 Price: $3.86 |
