| Ref | Part Number | Description |
|---|
| 2 |
670B2015 |
O RING,15MM Price: $1.42 |
| 3 |
41035-4001 |
PANEL-ASY,RR BRK Price: $484.61 |
| 4 |
112BA0622 |
BOLT-UPSET This part replaces 112G0622. Price: $3.74 |
| 5 |
410AA0600 |
WASHER-PLAIN-SMALL This part replaces 410B0600. Price: $1.31 |
| 6 |
41053-1004 |
LEVER,REAR BRAKE CAM Price: $139.52 |
| 7 |
92093-1004 |
OIL SEAL Price: $8.89 |
| 9 |
92027-1040 |
COLLAR,L=11.5 Price: $21.84 |
| 11 |
41050-1002 |
CAM SHAFT,BRAKE Price: $49.44 |
| 13 |
41048-1107 |
SHOE-BRAKE This part replaces 42019-011. Price: $37.39 |
| 14 |
42020-004 |
SPRING-BRAKE SHOE Price: $8.51 |
| 15 |
41034-1019 |
DRUM-ASSY,RR BRK Price: $488.13 |
| 16 |
601B6204UU |
BEARING-BALL,6204UUC3 Price: $29.98 |
| 17 |
92027-1207 |
COLLAR,REAR BRAKE Price: $45.82 |
| 18 |
601B6003U |
BEARING-BALL,#6003UC3 Price: $22.40 |
| 19 |
481J3500 |
CIRCLIP-TYPE-C,35MM Price: $1.96 |
| 20 |
92027-4005 |
COLLAR,REAR AXLE,L.H Price: $23.67 |
| 21 |
92015-1015 |
NUT,16M/M Price: $24.00 |
| 22 |
92001-1041 |
BOLT,FLANGED,8X36 Price: $9.86 |
| 23 |
42041-4001 |
SPROCKET,REAR,48T Price: $121.16 |
| 25 |
92058-1002 |
CHAIN JOINT 520 Price: $10.92 |
